QS Basics Elegant 600mm High Double Panel Horizontal Radiator

Finishes: Anthracite / Satin White



5-7 Working Days Approx

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Select Variations
You've Selected: OP-235786 - W 586mm x H 600mm - Anthracite
Key Features
  • Manufactured using steel material
  • CE and UKCA Approval
  • Fully Certified BS EN 442-1:2014
  • Five years guarantee from the manufacturer
SKU Code: QS-V101740

MFC Code: QSB-2104

QS Basics Elegant QSB-2104 Details

QS Basics Elegant 600mm High Double Panel Horizontal Radiator

  • Available in 2 finishes: Satin White and Anthracite.
  • Available in 2 widths: 586mm and 1572mm.
  • Size: Depth 94mm (9.4cm) x Height 600mm (60cm).
  • Suitable for wall-mounted installation.
  • Wall to the centre of tappings: 51.
  • Type of heat: water.
  • No. of heat setting: 1.
  • Projection from wall: 110mm (11cm).
  • All tappings are 1/2inch British standard pipe.
  • Supplied with fixing screws and brackets.
  • After installing any new radiators, when refilling the system, it is recommended that a suitable inhibitor is used.
  • Valves shown in the image are not included.
  • For more details, refer Production Variation Info and MFC Code tab shown below.
  • Refer to the technical drawing for more details..

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Elegant
  • ⤷ Colour
  • : Anthracite
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Material
  • : Steel
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Width
  • : 586
  • ⤷ Projection (Depth)
  • : 94
  • ⤷ Height
  • : 600
  • ⤷ Orientation
  • : Horizontal
  • ⤷ BTU Output
  • : 30°C - 965 | 50°C - 1863 | 60°C - 2360
  • ⤷ Watts
  • : 30°C - 283 | 50°C - 546 | 60°C - 692
  • ⤷ Fuel Type
  • : Central Heating
  • ⤷ Wall to Centre of Inlet
  • : 51
  • ⤷ Panel Configuration
  • : Double

Total: £164.77 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

BTU Output

BTU Output

It is the short form of a British thermal unit (BTU or Btu) and is defined as the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit. It is a standard unit against which radiator efficiency is measured.

CE Certified Product

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.

UKCA Certified

UKCA Certified

UKCA or the UK Conformity Assessed marking is a mandatory UK product marking for products sold across Great Britain, equivalent to the CE Marking in Europe. UKCA will be used to replace the CE Marking. CE marking will no longer be valid in England, Scotland and Wales except in Northern Ireland from the 1st of January 2021, and the CE mark will stay valid until the 1st of January 2023. A product with UKCA marking shows that the product complies with the UKCA Marking requirements.

Watts Output

Watts Output

Unit of power to measure electric current.

Product Variations Info & MFC Code
Details For 600mm High Horizontal Double Panel Radiator
Radiator Sizes 586mm Wide 1572mm Wide
Number Of Sections / Panels 20 54
BTU @ 30 Deg. C 965 2894
Thermal Output @ 30 Deg. C - Watts 283 848
BTU @ 50 Deg. C 1863 5589
Thermal Output @ 50 Deg. C - Watts 546 1638
BTU @ 60 Deg. C 2360 7081
Thermal Output @ 60 Deg. C - Watts 692 2075
