Crosswater Foile Module 2 Handle Thermostatic Trimset With Bath Spout

Foile FOMOD1601LBPC Details

Crosswater Foile Module 2 Handle Thermostatic Trimset with Bath Spout has a simple wall mounting arrangement and a highly modern use of geometry, which ensures this unit has a strong fashion sensibility. Fitted with lever handles with a sleek spout, this unit provides additional leverage for easier operation.

The wall-mounted controls deliver a sleek finish with plenty of character. Constructed from durable brass and given an exquisite coating that complements its minimalist, contemporary form, this trim set is perfect for inclusion in modern interiors. You can buy it in Chrome, Brushed Brass, or Matt Black finish. To gain maximum efficiency, install this trimset in high-pressure water systems only.

Key Features

✔Available in 3 finishes: Chrome, Brushed Brass, Matt Black
✔Headwork: 3/4 Inch quarter turn ceramic cartridge
✔Manufactured using brass material
✔15 years of guarantee against any manufacturing defects

Available in 2 variations: Without Handset, With Handset And Hose.
Diameter of trim-set: Ø70mm.
Size of 2 outlet valve: 296mm x 141mm x 119mm [Width x Depth x Height].
Size of 3 outlet valve: 401mm x 141mm x 119mm [Width x Depth x Height].
Spout projection: 269mm.
Centre of the inlet to centre of the outlet of spout: 234mm.
Inlet connections thread: G 1/2 Inch.

Flow regulator: Cache M18.5x1.
Suitable for high water pressure system.
Works on a minimum 1 bar to 5.0 bar water pressure system.
Maximum static pressure: 10.0 bar.
Concealed valve not included and sold separately.
Refer to the technical diagram for complete technical dimensions.
Download the installation instructions PDF from the additional info section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Foile
⤷ Handle Position
: Right
⤷ Colour
: Chrome, Brushed Brass, Matt Black
⤷ Warranty/Guarantee
: 15 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ No. of Holes Required
: 3, 4
⤷ Spout type
: Fixed

⤷ Valve/Cartridge Type
: 3/4 Inch Quarter Turn Ceramic Cartridge
⤷ Spout Reach
: 234
⤷ Inlet Connections
: G 1/2 Inch, G 3/4 Inch
⤷ Minimum Operating Pressure (Bar)
: 1
⤷ Hose Included
: Yes
⤷ Handle Style
: Lever
⤷ Flow Regulator Included
: Yes
⤷ Barcode
: 5056553420524
⤷ Product Type
: Thermostatic Trimset With Bath Spout

Additional Info & Downloads

Download the Product Data Sheet Of Tap Pdf File Download the Product Data Sheet Of Valve Pdf File Download the Installation Instruction Pdf File

Technical Images

Crosswater Foile Module 2 Handle Thermostatic Trimset With Bath Spout

Total: £432.99 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Quarter Turn

Operating these taps is almost effortless; it can be turned on and off by rotating the lever at 90 degrees. These taps have such low friction that they are perfect for people with arthritis, weak grip, the elderly and the young.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Flow Regulator

As the name suggests, a flow regulator is a simple device designed to regulate water flow to a predetermined level. The job of a flow regulator is to stop water wastage. For instance, if the regular flow rate through a tap is 20 litres per minute, a flow regulator can reduce the flow rate between 6 to 12 litres per minute to complete the desired chore without feeling low pressure.
