Mira Assist Plus Bath Shower Mixer Tap With Slide Rail Kit Chrome

£280.51

RRP: £361.15

STOCK AVAILABLITY:

In-Stock In Stock

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Delivery in 2 Working Days Approx.
Key Features
  • WRAS, TMV2, and KIWA UK-approved product
  • Five-year warranty from Mira against manufacturing defects
  • Mira Cool Shield™ to ensure the valve doesn’t get hot to the touch during use
  • Automatic shut down: Shut down within 2 seconds to comply with TMV2 requirements
SKU Code: QS-V107587

MFC Code: 1.1900.028

Mira Assist 1.1900.028 Details

Affordability and arresting looks – Mira Assist plus Bath Shower Mixer Tap with Slide Rail Kit has both these qualities. The tap features a fine-quality ceramic cartridge that enables precise and effortless water and temperature control and smooth unit handling. This model is attractive in durable chrome finish and is easy to install and clean.

The wall-mounted installation of this brassware ensures it won't waste much space. Suitable for both low and high-pressure systems, it enjoys a five-year warranty from the manufacturer. Good quality, outstanding performance – there is no reason for you not to buy this brassware. Dive into the sophistication it brings, ensuring every bath or shower is a moment of sheer elegance and comfort. Suitable to use with straight, double-ended, corner and steel baths.

  • The manufacturing code of this product is 1.1900.028
  • It comes in a chrome finish
  • Width of tap: 300mm (30cm)
  • Inlet Centres: 180mm (18cm)
  • Height of Slide bar: 560mm (56cm)
  • One spray 90mm (9cm) hand shower
  • 1750mm (175cm) flexible shower hose
  • Suitable for deck-mounted installation
  • supplied with rub clean nozzles
  • Bath Shower Mixer supplied with slide bar with adjustable fixing centres 400 - 520 mm (40cm - 52cm)
  • Thermostatic temperature stability
  • Standard deck mount, easy-fit elbows and integrated supply isolation
  • Compatible with all systems, even at low pressure
  • Simple lever handles are easy to grip and easy to use
  • Deck mount elbows allow bath-edge installation
  • Separate flow and temperature controls
  • Temperature control has a maximum temperature stop for increased safety (with an override for a hotter bath)
  • Temperature control type: Thermostatic
  • Flow control type: Ceramic
  • Temperature stability: ± 2°C
  • Deck mounted easy fit elbows support 2nd fix valve installation
  • Standard 180 mm (18cm) centres for the replacements of existing Bath Shower Mixers
  • Inlet connections: 3/4inch BSP male under bath connections to pipework; 3/4inch BSP connection to a mixer shower
  • Factory set to safe max temp: 39°C at maximum temperature stop, 46°C using override
  • Adjustable maximum temperature for on-site conditions
  • Flow rate: 15 l/min at 0.6 bar (at bath outlet) and 9 l/min at 0.5 bar (at handset)
  • Flow regulator: 6 l/min (for handset only) supplied with the product
  • Cold water range: 1°C to 25°C
  • Hot water range: Min 55°C; 60°C - 65°C (recommended)
  • Minimum maintained pressure (gas water heater) 1 bar (10-metre head)
  • Minimum maintained pressure (gravity system): 0.1 bar (1-metre head)
  • Maximum maintained pressure: 5.0 bar (50-metre head)
  • Maximum static pressure: 10.0 bar (100-metre head)
  • Download the Customer Datasheet PDF File from the Additional Info Section
  • Refer to the technical drawing for more details
  • Integrated bi-directional 1/4 turn full-bore ball valve isolators:
  • Saves time and resources when conducting in-service cold failure testing to comply with TMV 2
  • Saves time and resources for in-service maintenance (i.e cleaning filters and not having to remove bath panel)
  • No specialist tools required: Easily isolate the water supply using a flathead screwdriver or hex key

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Chrome
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Theme
  • : Modern
  • ⤷ Inlet Connections
  • : 3/4inch BSP
  • ⤷ Minimum Operating Pressure (Bar)
  • : 1
  • ⤷ Hose Included
  • : Yes
  • ⤷ Hose Length
  • : 1750
  • ⤷ Configuration
  • : Slide Rail | Hand Shower | Hose
  • ⤷ Height
  • : 560
  • ⤷ Compliance/Approvals/Standard
  • : KIWA-UK | WRAS | TMV2
  • ⤷ Soap Dish Included
  • : Slide Rail
  • ⤷ Riser Rail & Kit Finish
  • : Chrome
  • ⤷ Handset Included
  • : Yes
  • ⤷ Rail Length
  • : 520
  • ⤷ Adjustable Height
  • : Yes

Additional Info & Downloads

Download PDFDownload the Customer Data Sheet Pdf File

£280.51
RRP: £361.15
IN-STOCK In Stock Delivery in 2 Working Days Approx.
QS Supplies

1 Features Included In This Product Explained

Static Pressure

Static Pressure

The pressure exerted by water on the tap body when the tap is closed and no water is flowing. This represents the force of water in the system when the tap is at rest.
