Ideal Standard Ceratherm T100 Dual Exposed Thermostatic Shower System

Ceratherm A7594AA Details

Ideal Standard Ceratherm T100 Dual Thermostatic Shower System shows what great showering is all about. The shower system, which easily mounts to the wall, is manufactured using solid brass. The assortment also includes a rain showerhead, hand shower and idealflex hose.

Pack Includes:-.
ø300mm round rainshower on swivelling arm, 1 function stick hand spray and 1.75cm Idealfex hose.
Inlet centre of the valve: 150mm [15cm].
Valve width: 304mm [30.4cm].
Valve inlet diameter: 70mm [7cm].
Slide rail length: 1191mm [119.1cm].
Weight: 5.74 kg.
The diverter integrated into the handle.
Integrated rotary ceramic diverter to select headset or showerhead.
Easy-mount adjustable bracket for easy replacement.
Height adjustable shower holder on the rail.
Flow rate: 8 litres per minute at 3 bar water pressure.
Removable 12 litres per minute eco flow regulator fitted in the fixed head and 8 litres per minute regulator in the hand spray.
Specification:.

Cool Body.
Minimalistic cylindrical design with 2-in-1 pin handle - easy grip and override button.
Features Precitherm® cartridge for precise temperature control, including adjustable temperature limit.
Temperature safety button.
Water and energy-saving functionality.
Easy to clean materials and design.
Limescale resistant with rub-clean nozzles.
The recommended minimum operating water pressure is 0.5 Bar.
Suitable for high water pressure system.
Adjustable maximum hot temperature limit stop for customized comfort.
Equipped with a thermostatic cartridge for precise temperature regulation.
For complete size details, please refer to the technical drawing.
Download the Installation and Fitting instruction PDF provided in the additional info tab.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome | Brushed Brass | Magnetic Grey | Silver Storm
⤷ Weight in kg
: 5.74
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Thermostatic
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Water Saving
: Yes
⤷ Hose Included
: Yes
⤷ Hose Length
: 1700
⤷ Spray Setting
: 1
⤷ Temperature Control
: Thermostatic

⤷ Anti-Scald
: Yes
⤷ Diverter Included
: Yes
⤷ Compliance/Approvals/Standard
: WRAS And TMV Approved
⤷ Product Type
: Shower Sets
⤷ Showerhead Type
: Swivelling
⤷ Showerhead Finish
: Chrome | Brushed Brass | Magnetic Grey | Silver Storm
⤷ Riser Rail & Kit Finish
: Chrome | Brushed Brass | Magnetic Grey | Silver Storm
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: 1
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: Ø300
⤷ Rail Length
: 1191
⤷ Diverter Type
: Integrated
⤷ Adjustable Height
: Yes

Additional Info & Downloads

Download the Installation Instruction Pdf File Download the Spare Part List Pdf File Download the Flow Rate Pdf File

Total: £553.37 5-7 Working Days Approx QS Supplies

7 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

TMV2 Approved Product

TMV2 is an independent certification for thermostatic mixers, including shower valves, run by BuildCert that ensures national and international standards as specified under (BS EN 1111 and 1287) are met. These standards detail the exacting requirements that a thermostatic valve or product must comply with to guarantee a high thermostatic protection and safety standard. Products meeting this requirement carries the logo and protect against any scalding accidents.

Cool Body Technology

This feature has been made with your safety in mind because the thermostatic surface is always cool and never heats up, keeping it safe to touch.

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Integrated Flow Rate Limiter

Integrated Flow Rate Limiters limit the rate at which water flows from the showerheads. In hand showers, the manufacturers limit the flow rate to eight litres/min, and in showerheads, they restrict the flow to either 9.5 litres/min or 12 litres/min. The flow rate may vary depending on the manufacturer. With this eco-friendly feature, you can save on water consumption and bills.

Rub Clean

Any limescale deposits can simply be wiped clean with a clean cloth - no need to scrub or use harsh cleaners.
