Aqualux Framed 8 Clear Glass 2000mm Height Bi-Fold Door

Framed 8 1198870 Details

Aqualux Framed 8 Clear Glass Bi-Fold Door will provide you with a greater value for your money. It has a nice appearance, requires little upkeep, and is very high quality. Accidents are also not a concern thanks to the use of toughened glass construction that is stable and solid.

This door has a reversible construction and can be installed on either the right or left side. The door is a delight to use, thanks to the metal handles, which offer a smooth, luxurious grip. The Aquagleam anti-limescale coating means that the door maintains its cleanliness for a long time. Suitable to use with a rectangle or square shower trays.

Available in 3 sizes: 760mm, 800mm, 900mm.
Glass thickness: 8mm (0.8cm).
Overall height: 2000mm (200cm).
20mm adjustment tolerance.
Polished chrome metal handles.
Wall profile adjustment of 20mm per profile.
Reversible design.
Refer to the technical diagram for complete technical dimensions.
Download the product data sheet PDF from the additional info section.
Details Of 760mm Door:.
Size In [mm]: 760mm x 2000mm [Width x Height].
Size In [cm]: 76cm x 200cm [Width x Height].
Entry Width: 508mm (50.8cm).
Adjustment: 724mm - 764mm (72.4cm - 76.4cm).

Weight: 26kg.
Details Of 800mm Door:.
Size In [mm]: 800mm x 2000mm [Width x Height].
Size In [cm]: 80cm x 200cm [Width x Height].
Entry Width: 560mm (56cm).
Adjustment: 764mm - 804mm (76.4cm - 80.4cm).
Weight: 27kg.
Details Of 900mm Door:.
Size In [mm]: 900mm x 2000mm [Width x Height].
Size In [cm]: 90cm x 200cm [Width x Height].
Entry Width: 652mm (65.2cm).
Adjustment: 864mm - 904mm (86.4cm - 90.4cm).
Weight: 30kg.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Framed 8
⤷ Handle Finish
: Polished Chrome
⤷ Weight in kg
: 26, 27, 30
⤷ Warranty/Guarantee
: 12 Years
⤷ Width
: 760, 800, 900
⤷ Height
: 2000
⤷ Barcode
: 5014753053799
⤷ Door Type
: Bi-Fold

⤷ Frame Design
: Framed
⤷ Frame / Profile Finish
: Polished Silver
⤷ Glass Type
: Clear Toughened
⤷ Glass Thickness
: 8
⤷ Number Of Doors
: 1
⤷ Entry Width
: 508, 560, 652
⤷ Handle Included
: Yes
⤷ Door Opening
: Right Or Left Hand Side

Additional Info & Downloads

Download the Product Data Sheet Pdf File

Total: £312.76 10-14 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Reversible Design

It is a design which allows the product to be fitted either to the right or left, depending on the dimensions of your space.

Toughened Safety Glass

Toughened glass, tempered or safety glass as it is rightly called, is five times harder than regular glass of the same size and thickness, which makes it so that it won’t break as easily. It also shatters with scattering as it tends to break into tiny, blunt pieces without harming anyone nearby. Known to have greater thermal strength, this durable material with double glazing has almost twice the soundproofing abilities and provides excellent heat insulation.

Adjustable Wall Profile

These refer to the pieces of material that fit the shower door or panel against a wall and can be adjusted to allow for out-of-true walls for a neat and seamless installation. The ability to adjust the side profile gives a perfect fit and makes the installation process easy. Depending on the manufacturer, the profile can be adjusted between 12 to 30mm.
