Mira React Deck Mounted Thermostatic Chrome Bath Shower Mixer Tap

Mira React 1.1900.020 Details

Mira never ceases to amaze buyers with its fantastic range of products. The latest example is this Thermostatic Bath Shower Mixer Tap from the brands React range. The product, suitable for all plumbing systems, even at low pressure, features the latest thermostatic technology with maximum temperature stop for increased safety.

Together with Mira Cool Shield™ to ensure the shower valve doesnt get hot to touch, it provides no scalding or burning. Crafted from materials of the finest quality, it boasts KIWA, WRAS, and TMV2 approvals. Order it from our online store to earn a good discount.

Available in different variants: Without Shower Set and With Shower Set - [Optional].
It comes in a chrome finish.
Standard deck mount, easy-fit elbows.
Compatible with all systems, even at low pressure.
Slide bar with adjustable fixing centres 400 - 520mm (40cm - 52cm).
Temperature control has a maximum temperature stop for increased safety (with an override for a hotter shower).
Flow control incorporates a diverter to allow an easy switch between shower and bath fill.
Easy fit elbows, supports 2nd fix valve installation.
Inlet connections: 3/4inch BSP male under bath connections to pipework; 3/4inch BSP connection to a mixer shower.
Outlet connections to shower: 1/2 inch BSP Male.
Reversed inlets supported: No - hot left, cold right only.
Factory set to safe max temp: 39° C at maximum temperature stop (ideal for showering), 46° C using override (ideal for bath fill).
Adjustable maximum temperature for on-site conditions.
Flow rate (at handset): 9 l/min at 0.5 bar.

Flow rate (at bath outlet): 15 l/min at 0.6 bar.
Flow regulator: 6 l/min (for handset only, supplied with the product).
Temperature stability: ± 2°C.
Cold water range: 1°C to 25°C.
Hot water range: Min 55°C; 60°C - 65°C (recommended).
Minimum maintained pressure (gas water heater): 1 bar (10-metre head).
Minimum maintained pressure (gravity system): 0.1 bar (1-metre head).
Maximum maintained pressure: 5.0 bar (50-metre head).
Maximum static pressure: 10.0 bar (100-metre head).
Refer technical drawing for more details.
Details For Bath Shower Mixer Tap With Shower Set:.
The handset comes with rub-clean nozzles.
One spray 90mm (9cm) hand shower.
1750mm (175cm) flexible shower hose.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: React
⤷ Water Activation
: Rotating
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Left | Right
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 2
⤷ Valve Included
: Yes

⤷ Inlet Centres
: 180
⤷ Width
: 300
⤷ Inlet Connections
: 3/4inch BSP Male
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Flow Rates (l/min)
: 9 l/min at 0.5 bar (at handset) | 15 l/min at 0.6 bar (at bath outlet)
⤷ Handle Style
: Knob
⤷ WRAS Approved
: Yes
⤷ Compliance/Approvals/Standard
: KIWA-UK | WRAS | TMV2
⤷ Barcode
: 5013181108033
⤷ Product Type
: Bath Shower Mixer Tap

Total: £208.26 5 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

TMV2 Approved Product

TMV2 is an independent certification for thermostatic mixers, including shower valves, run by BuildCert that ensures national and international standards as specified under (BS EN 1111 and 1287) are met. These standards detail the exacting requirements that a thermostatic valve or product must comply with to guarantee a high thermostatic protection and safety standard. Products meeting this requirement carries the logo and protect against any scalding accidents.

Mira Cool Shield™

With the purpose of giving you enhanced safety during showering, the cool shield technology features in all of Mira's mixer showers. This is an innovative technology that prevents heating up of the valve during a shower, so it remains cool to the touch, making it ideal for use in homes with children or elders.

Static Pressure

The pressure exerted by water on the tap body when the tap is at rest in relation to the pressure.
