Villeroy And Boch Architectura 370 x 530 x 316mm Rimless Wall-Hung WC Pan With Seat

£424.25

RRP: £577.20

STOCK AVAILABLITY.

In-Stock In Stock

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Delivery in 4 Working Days Approx.
Key Features
  • Supplied with seat and cover
  • Features rimless WC Pan
  • Pan material: Sanitary ceramics
  • Toilet seat and cover material: Duroplast
  • Two years of warranty against any manufacturing defects
SKU Code: QS-V109896

MFC Code: 5685HR01

Villeroy And Boch Architectura 5685HR01 Details

Villeroy and Boch Architectura Rimless WC Pan with Seat and Cover have a fabulous white finish that facilitates cleaning while blending effortlessly with any bath area decor. Suitable for use within a modern bathroom setting, it is crafted from high-grade material for extended use. Extremely hygienic to use, it is best suited for use with compatible bidets for double the comfort; you can look at the range of bidets available at our online store.

The wall-hung installation is designed with a compatible soft close seat and cover; this washdown toilet is stunning and space-saving. The rimless design makes for significantly easier cleaning and is a clear improvement in hygiene over standard models.

  • The manufacturing code of this product is 5685HR01.
  • It comes in a White Alpin finish.
  • Installation: wall-mounted.
  • Size: 370mm x 316mm [Width x Height].
  • Projection: 530mm.
  • Weight: 22 kg.
  • Suitable for: Concealed cistern.
  • Flush type: Washdown toilet.
  • Flush volume l: 3 / 4,5 l.
  • Outlet: horizontal outlet.
  • Function: with automatic lowering mechanism [SoftClosing] with removable seat [QuickRelease].
  • Leed: 4.
  • Toilet seat and cover surface: glossy.
  • Download the installation instructions PDF and Data Sheet from the Aditional Info section.
  • Refer to the technical diagram for the complete technical dimensions.

Info / Size (mm)

  • Toilet
  • Width: 370 mm
  • Projection: 530 mm
  • Height: 316 mm

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Architectura
  • ⤷ Toilet Design
  • : Wall-Hung Toilet
  • ⤷ Colour
  • : Alpin White
  • ⤷ Weight in kg
  • : 22
  • ⤷ Warranty/Guarantee
  • : 2 Years
  • ⤷ Material
  • : Sanitary Ceramics
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall-Hung
  • ⤷ Pan Width
  • : 370
  • ⤷ Pan Height
  • : 316
  • ⤷ Projection (Depth)
  • : 530
  • ⤷ Cistern Included
  • : Sold Separately
  • ⤷ Flush Type
  • : Washdown Toilet
  • ⤷ Full Flush Volume in litres
  • : 4.5
  • ⤷ Half Flush Volume in litres
  • : 3
  • ⤷ Outlet
  • : Horizontal
  • ⤷ Seat Included
  • : Yes
  • ⤷ Seat Type
  • : Standard
  • ⤷ Seat Finish
  • : White Alpin
  • ⤷ Barcode
  • : 4051202373528
  • ⤷ Bowl Shape
  • : Square
  • ⤷ Pan fixing centres
  • : 180
  • ⤷ Outlet Diameter
  • : 102
  • ⤷ Floor to centre of cistern fixing hole
  • : 320
  • ⤷ Base to centre of outlet
  • : 220


Additional Info & Downloads


Total: £424.25 5-7 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Washdown Model

Washdown Model

A washdown toilet uses the weight of the water and gravity to push out the toilet waste from the toilet bowl. The washdown toilet is designed with a short and wide trapway, so that waste can quickly enter the trapway using just the force of water from the tank. A washdown model includes a push-button flush and has a skirted design with a smaller water surface area and a short trapway and can easily handle heavy loads without getting clogged.

Rimless

Rimless

A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards its edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Horizontal Outlet

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.
