Duravit No.1 Wall Mounted Rectangular Furniture Washbasin

Duravit No.1 07434500002 Details

Duravit No.1 Wall Mounted Rectangular Furniture Washbasin can be purchased in two sizes, 450mm and 500mm. Designed in a typical rectangular shape with gently curved edges, this unit is manufactured from sleek and durable sanitary ceramic to last years of frequent use. The material is rugged and hard-wearing and scratch and stain-resistant. This product is ideal for single bore basin taps; this product makes a gorgeous addition to any modern or contemporary bathroom layout and is compatible with overflow. The basin has a fully glazed underside for better hygiene and is backed by a 5 Years warranty from the manufacturer against manufacturing defects.

Available in different widths: 450mm and 500mm - [Optional].
It comes in a white Alpin finish.
Suitable for wall mounted installation.
Rectangular shape.
Easy-clean and hygienic surface.
Suitable for installing with furniture.
Ideal for single-bore faucets.
Ideal for bathrooms with a small floor plan or the guest bathroom.
Underside fully glazed for better hygiene.
The tap shown in the image is not included.

Download the Mounting Instruction PDF File from the Additional Info Section.
Refer to the technical drawing for more technical specifications.
Details For 450mm Basin:.
Size [mm]: 450mm x 350mm x 140mm [Width x Depth x Height].
Size [cm]: 45cm x 35cm x 14cm [Width x Depth x Height].
Weight: 9.7kg.
Details For 500mm Basin:.
Size [mm]: 500mm x 400mm x 145mm [Width x Depth x Height].
Size [cm]: 50cm x 40cm x 14.5cm [Width x Depth x Height].
Weight: 11kg.

Info / Size (mm)

Basin
Width: 450 mm
Depth: 350 mm
Height: 140 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Basin Underside
: Glazed
⤷ Range
: No.1
⤷ Coating
: Without Coating
⤷ Colour
: High Gloss White
⤷ Weight in kg
: 9.7
⤷ Shape
: Rectangular
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Ceramic
⤷ Theme
: Modern
⤷ Projection (Depth)
: 350
⤷ Width
: 450
⤷ Height
: 140
⤷ Inner Bowl Width
: 405

⤷ Inner Bowl Depth
: 215
⤷ Distance rear edge to centre of waste hole
: 180
⤷ Fixing Holes Centre
: 180
⤷ Distance top edge to centre of fixing hole
: 55
⤷ Distance rear edge to centre of tap hole
: 65
⤷ Depth of tap platform
: 110
⤷ Number of bowls
: 1
⤷ No. of Tap Holes
: 1
⤷ Tap Hole Position
: Center
⤷ Overflow Included
: Yes
⤷ Compliance/Approvals/Standard
: CE
⤷ Barcode
: 4063382180247
⤷ Product Type
: Furniture Washbasin

Additional Info & Downloads

Download the Mounting Instruction Pdf File

Total: £81.54 5-7 Working Days Approx QS Supplies

3 Features Included In This Product Explained

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.

Sanitary Ceramic

Sanitary ceramic material is a type of ceramic used in the manufacture of sanitary ware or bathroom ware. It is mainly composed of ceramic, and is waterproof and durable. Its surface is hard, smooth and non-porous, making it hygienic and easy to clean.

Questions & Answers

Submit Your Questions 2 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Gary Asked :
Hi. Can this basin be set on a countertop?

Answered By QS Team

It is a hand rinse basin glazed underneath, so it is unsuitable as a countertop basin.

Was this answer helpful?

kevin Asked :
Can this basin be fixed to a solid brick wall, or does the wall need to be hollow?

Answered By QS Team

We advise fitting on stud walls - if the wall isn’t strong enough to hold the weight of the basin, you will need an inwall carrier for this or for the fitter to strengthen the wall.

Was this answer helpful?
