Nuie Windon Triple Thermostatic Chrome Shower Valve With Kit And Head

Nuie Bathroom Windon SBS43TR2 Details

Put together your brand new, ultra-modern shower with the help of the Niue Windon Triple Thermostatic Chrome Shower Valve with Kit and Head. This kit includes a valve, fixed head, arm, shower kit and elbow, all made in solid metal and ideal for use with any low-pressure water system. Inside the unit is a processor that contains a built-in thermostat that checks the water temperature to ensure that the water is always staying as close as possible to the preset temperature. Pack provides everything you need for a single-outlet showering experience and is backed by a five-year guarantee from the manufacturer against manufacturing defects.

Manufacturing code of this products : SBS43TR2.
Completes Set in chrome finish.
Specifications For Slide Rail Kit :.
Height : 700mm (70cm).
Weight : 0.68kg.
Manufactured using brass and ABS material.
Mount type : Surface and Wall.
No of outlet : 1.
Pipe Size: 15mm (1.5cm) (1/2inch BSP).
Suitable for low water pressure system.
Required minimum 0.1 bar water pressure.
Specifications For Triple Shower Valve :.
Size [mm]: 80mm x 135mm x 300mm [Width x Depth x Height].
Size [cm]: 8cm x 13.5cm x 30cm [Width x Depth x Height].
Weight : 3.45kg.
Manufactured using brass and ABS material.
Mount type : Recessed and Wall.
No of outlet : 2.
Pipe Size: 15mm(1.5cm) and 22mm(2.2cm).
Valve Cartridge : 1/4 Turn Ceramic Disc.
Suitable for low water pressure system.
Required minimum 0.1 bar water pressure.
Specifications For Shower Arm :.

Length : 350mm (35cm).
Weight : 0.5kg.
Manufactured using brass material.
Mount type : Surface and Wall.
No of outlet : 1.
Specifications For Shower Head :.
Diameter : Ø200mm (20cm).
Weight : 0.72kg.
Shape : Square.
Manufactured using brass and ABS material.
Mount type : Wall and Surface.
Suitable for low water pressure system.
Required minimum 0.2 bar water pressure.
Specifications For Outlet Elbow :.
Size [mm]: 36mm x 36mm x 53mm [Width x Depth x Height].
Size [cm]: 3.6cm x 3.6cm x 5.3cm [Width x Depth x Height].
Weight : 0.23kg.
Manufactured using brass and ABS material.
Mount type : Surface and Wall.
Download Customer Data Sheet PDF File from the Additional Info Section.
Technical drawing available for more technical Specification.
Five years guarantee from Nuie against manufacturing defects.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: ABS | Brass
⤷ Theme
: Modern
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Configuration
: Valve | Fixed Head | Arm | Shower kit | Elbow
⤷ Height
: 300

⤷ Backplate Width
: 80
⤷ Backplate Height
: 280
⤷ Riser Rail & Kit Finish
: Chrome
⤷ Shower Head Included
: Yes
⤷ Shower Head Size
: Ø200
⤷ Rail Length
: 700
⤷ Outlet Elbow Included
: Yes

Additional Info & Downloads

Download the Customer Data Sheet Pdf File

Total: £272.59 2 Working Days Approx QS Supplies

3 Features Included In This Product Explained

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Michael Asked :
I am interested in the Nuie Windon Triple Thermostatic valve with a shower kit included. Could you let me know if this valve also has a diverter?

Answered By QS Team
