MHS Rads 2 Rails Holborn Vertical 1866mm High Aluminium Radiator

QS-V100313

MFC CODE: HOVWH-1866-03

£206.40

RRP: £306.00

STOCK AVAILABILITY

4 Working Days Approx

Not Yet Rated No Rating

Review this Product

Shipping: £29.95

Variations
Technical
Available Sizes - QS-V100313 Step 1

Finishes - QS-V100313 Step 2

Please Note all the measurements are in 'mm'
Colour White, Volcanic
Warranty/Guarantee 10 Years
Material Aluminium
Installation Type Wall Mounted
Width 260, 340, 420, 500, 580, 660
Height 1866
BTU Output 3071, 4094, 5118, 6142, 7165, 8189
Watts 900, 1200, 1200, 1800, 2100, 2400
Tapping / Pipe Centres 260, 340, 420, 500, 580, 660
Valves Included Sold Separately
Fuel Type Central Heating
Pressure Tested (bars) 16

MHS Rads 2 Rails Holborn HOVWH-1866-03 DETAILS

MHS Rads 2 Rails Holborn Vertical 1866mm High Radiator is a Lightweight aluminium radiator with excellent outputs, making it a great option for larger rooms. It also has excellent thermal efficiency and fast heat-up times for low heating costs. Made in Italy, it is vertically oriented and is made from 100% recycled and recyclable aluminium. You can purchase it in White or Volcanic finish with an operating pressure of up to 16 bar. The model appliance can be purchased with a 10 years guarantee against any manufacturing defects.

  • Lightweight aluminium radiator has excellent outputs, making it a great option for large rooms
    It also has excellent thermal efficiency and fast heat up times for low heating costs
  • Made in Italy
  • Orientation : Vertical
  • Height : 1866mm
  • 100% recycled and recyclable aluminium
  • Finish: White / Volcanic
  • Operating up to 16 bar
  • Fast heat up times
  • Lightweight, low water content
  • Ideal for use with heat pumps
  • To calculate the output at Delta 30 degree C, multiply the outputs below by 0.515
  • Wall to face : 102mm
  • Tapping from wall : 67mm
  • Valves and pipe sleeve not included - available separately [Se Option Below]
  • Images shown is for illustration purpose only. Actual product may vary due to product enhancement
  • Refer technical diagram for complete technical dimensions
  • 10 years guarantee against any manufacturing defects.



Technical Images


CUSTOMISE YOUR PRODUCT
OTHER SIZES / FINISHES
Sizes Available
Other Sizes / Finishes / Variations Available.
QS Code Finish Size / Difference MFC Code
QS-V9310 - 1466mm Height HOVWH-1466-03



PRODUCT VARIATIONS INFO & MFC CODE
MFC Code For White And Volcanic Finish
White
SECTION WIDTH HEIGHT CENTERS WATTS BTU Dry Weight kg Water Content ltrs MFC CODE
3 260mm 1866mm 260mm 900 3071 10.2 2.34 HOVWH-1866-03
4 340mm 1866mm 340mm 1200 4094 13.6 3.12 HOVWH-1866-04
5 420mm 1866mm 420mm 1500 5118 17 3.9 HOVWH-1866-05
6 500mm 1866mm 500mm 1800 6142 20.4 4.68 HOVWH-1866-06
7 580mm 1866mm 580mm 2100 7165 23.8 5.46 HOVWH-1866-07
8 660mm 1866mm 660mm 2400 8189 27.2 6.24 HOVWH-1866-08
Volcanic
SECTION WIDTH HEIGHT CENTERS WATTS BTU Dry Weight kg Water Content ltrs MFC CODE
3 260mm 1866mm 260mm 900 3071 10.2 2.34 HOVV-1866-03
4 340mm 1866mm 340mm 1200 4094 13.6 3.12 HOVV-1866-04
5 420mm 1866mm 420mm 1500 5118 17 3.9 HOVV-1866-05
6 500mm 1866mm 500mm 1800 6142 20.4 4.68 HOVV-1866-06
7 580mm 1866mm 580mm 2100 7165 23.8 5.46 HOVV-1866-07
8 660mm 1866mm 660mm 2400 8189 27.2 6.24 HOVV-1866-08
