Flova Spring Concealed Thermostatic Shower Valve, Handset & Hose, SRTHGO3-V

Flova Spring Details

MFC: SRTHGO3-V

The Flova Spring Concealed Manual GoClick Button Horizontal Shower Valve is designed with full-flow control. It features EasyFix installation which allows for fast and simple placement within any compatible shower space. Suitable for use as part of any high-pressure water system, this product requires 1.0 bar of water pressure to function properly. Complete with a safety temperature override button as well as anti-scald technology, this unit is created to keep any, and every, user safe during operation. Available in more than one model to choose from and boasting GoClick technology, this unit is elementary to operate as well.

Key Features

✔WRAS Approved
✔Manufactured using Solid Brass Material
✔Features GoClick® Technology
✔Integral Handshower Set
✔15-Year Guarantee from the Manufacturer Against any Manufacturing Defects

Choice of Outlets: 3 or 4 Outlets
Diamond Chrome Finish
Full flow Control
Easyfix Installation
Installation Type: Concealed
Horizontal Backplate
Size [mm]: 396 x 120mm [Width x Height]
Size [cm]: 39.6 x 12cm [Width x Height]
Advanced Anti-Scald Technology
Temperature Control: Thermostatic
Safety Temperature Override Button
Safety Override Button - 38°C Stop, Increase the Temperature By Pressing the Button to Keep Your Family Safe
Click & Go - Instant Flow and Smooth Operation, Have Full Control of your Outlets
Vernet Thermostatic Cartridge - Keeping you and Your Family Safe by Regulating Controlling the Water Temperature Without User Inteference
Recommended Minimum Water Pressure is 1.0 Bar - HP-High Pressure
When Installing this Product with a Shower Pump, a Negative Head Pump is Recommend for Optimum Performance

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Spring
⤷ Colour
: Diamond Chrome
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Min-Max Wall Mount
: 90-110
⤷ Inlet Connections
: 2x G 1/2"
⤷ Minimum Operating Pressure (Bar)
: 1
⤷ Hose Included
: Yes
⤷ Hand-Shower Included
: Yes
⤷ Handle Style
: Flat, Push Button
⤷ WRAS Approved
: Yes

⤷ Technologies
: GoClick
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 396
⤷ Backplate Height
: 120
⤷ Anti-Scald
: Yes
⤷ Number of Handles
: 3, 4
⤷ Number of Outlet
: 3, 4
⤷ Outlet Connection
: 2x G 3/4"
⤷ Orientation
: Landscape
⤷ Product Type
: Thermostatic Shower Valve
⤷ Plumbing Option
: Concealed
⤷ Concealed Body Included
: Yes
⤷ Cartridge Included
: Yes
⤷ Cartridge Type
: Vermet Thermostatic

Additional Info & Downloads

Download the Aftercare Guide Pdf File

This item can also be found in:

Concealed Shower Valves

Technical Images

Flova Spring Concealed Thermostatic Chrome Shower Valve with Handset and Hose - 3 or 4 Controls

3 Outlet

4 Outlet

£820.80

RRP: ~~£1026.00~~

STOCK AVAILABLITY: 6 Working Days Approx

QS Supplies

5 Features Included In This Product Explained

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws.
Read more...

3-Outlets

Also known as a triple valve, these valves feature three outlets, and either two or three can run simultaneously, depending on the manufacturer. You can also operate each outlet independently if required. The three outlet connections connect to three different fixtures, e.g., an overhead shower, body jets, side showers, or a bath mixer tap.

GoClick TECHNOLOGY

GoClick® technology in Flova makes life easy for the installer. The GoClick easy-fit box has been designed to allow accurate installation. It has 3/4 inch inlets for high-flow water pressure and a built-in spirit level, easy snap guides and offset fixing points for easing the installation process. The valve can be adjusted between 85 and 105mm to ease installation. The GoClick® mechanism enables water flow just with the click of a button. The user can enjoy a relaxing and intuitive showering experience. Products equipped with GoClick® are easy to operate, safe to use and offer consistent temperature without the risk of scalding. The built-in safety override button has been pre-set to 38 degrees Celcius and increases the temperature after the button is pressed. The button is within easy reach if you want to switch it back to 38 degrees Celcius.

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Temperature control

The Thermostatic mixers have a temperature control mechanism that keeps the temperature constant at all times.
