Niagara Portobello Single Lever Basin Mixer Tap Chrome With Waste

Niagara Portobello 9104 Details

The Niagara Portobello Single Lever Mono Basin Mixer Tap with Waste is suitable for installation within any modern bathroom design and features a stunning chrome finish that looks lovely as part of any style of decor. Designed for secure deck-mounted installation, this product is crafted for use within any low-pressure water system and requires between 0.2 bar minimum and 10-bar water pressure maximum for proper functionality. Featuring a body made of brass and a handle crafted from zinc, this unit is truly made to last through years of daily use.

Available in 2 Variants - Mini Mono and Mono Version [Optional].
It comes in a chrome finish.
Suitable for deck-mounted installation.
Height: Mono 145mm (14.5cm) - Mini Mono 118mm (11.8cm).
Flexible inlets.

Inlet Connections: 1/2 Inch BSP.
Centre of the inlet to Centre of outlet: Mono 102mm (10.2cm) Mini Mono: 80.5mm (8.05cm).
The pressure required: Min. 0.2 bar and max. 10 bar.
Refer to the technical drawing for more technical details.

Info / Size (mm)

Tap
Pipe Centre: 102 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting | Tilting
⤷ Range
: Portobello
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upward
⤷ Colour
: Chrome
⤷ Country of Origin
: UK
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Disc Cartridge

⤷ Handle Material
: Zinc
⤷ Base To Spout
: 63
⤷ Spout Reach
: 66.5
⤷ Overall Height
: 118
⤷ Width
: 42
⤷ Inlet Connections
: M10*1*1/2*400
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Waste Type
: Click-Clack
⤷ Flow Rates (l/min)
: 0.5 bar - 9.7 | 1 bar - 13.3 | 3 bar - 23.5
⤷ Handle Style
: Lever
⤷ Waste Included
: Yes
⤷ Barcode
: 5057199929129
⤷ Product Type
: Basin Mixer Tap

Total: £49.78 3-4 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
Read more...

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Monobloc Tap

A Monobloc/Mono tap has a single control lever that adjusts the mix of hot and cold water supplies and the flow rate. A mixer tap has two separate controls for hot and cold water. Both work equally well, and your choice will come down to aesthetics and how many tap holes your sink has. Monobloc taps are a neater solution and more modern in appearance.

Zinc

Zinc is a versatile lustrous, relatively brittle metal which finds many applications, as it is corrosion resistant and alloys easily with other metals to enhance their properties. Its important applications are galvanisation, and battery production. It is a good electrical conductor and also malleable so it can take on different shapes.
