Saneux Cos Concealed Three Way Thermostatic Shower Valve


RRP: £722.00


6 Working Days Approx.

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Select Variations
You've Selected: OP-132259 - Portrait - Chrome
Key Features
  • Available Finishes: Chrome, Matte Black
  • Fitted with a thermostatic cartridge for safety and peace of mind
  • Contemporary design
  • Manufactured using brass
  • 15-year guarantee for the body and Twelve months warranty for cartridge and other parts from the manufacturer
SKU Code: QS-V82613

MFC Code: CO321

Saneux Cos CO321 Details

Saneux Cos Three Way Thermostatic Portrait Shower Valve brings together an ergonomic design and visual sophistication in this contemporary presentation. This concealed unit features three outlets with diverter and three controls to switch between 2 separate outlets or different shower or bath functions. Its thermostatic functionality prevents accidental scalding accidents and offers enjoyable bathing and showering. It is included with a rectangular portrait faceplate and realise in hard-wearing brass metal. A value purchase, it is backed by 15 years of guarantee from the manufacturer against any manufacturing defects.

  • Available Variations: Portrait, Landscape.
  • Features 3 outlets with diverter and three control to switch between 2 separate outlets or different shower or bath functions [upper knob is for water flow on/off / 2-way diverter, the middle is for temperature and lower is for independent water flow on/off].
  • Size in [mm]: 120mm x 280mm [Width x Height].
  • Size in [cm]: 12cm x 28cm [Width x Height].
  • Faceplate thickness is 3mm.
  • Minimum wall depth cavity required: 80mm [8cm].
  • WRAS approved.
  • Inlet Connections : 2 x 1/2 inch BSP Female.
  • Outlet Connections : 3 x 1/2 inch BSP Female.
  • The minimum water pressure recommended for smooth working is 0.2 bar [LP-Low Pressure].
  • The minimum flow rate is 7.2 litres per minute at 0.2 bar water pressure.
  • Refer to the technical diagram for the complete technical dimensions.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Chrome, Matte Black
  • ⤷ Shape
  • : Rectangular
  • ⤷ Warranty/Guarantee
  • : 15 Years
  • ⤷ Material
  • : Brass
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Inlet Connections
  • : 2 x 1/2" BSP Female
  • ⤷ Minimum Operating Pressure (Bar)
  • : 0.2
  • ⤷ Flow Rates (l/min)
  • : 7.2-0.2 Bar
  • ⤷ Handle Style
  • : Lever
  • ⤷ WRAS Approved
  • : Yes
  • ⤷ Temperature Control
  • : Thermostatic
  • ⤷ Backplate Width
  • : 120
  • ⤷ Backplate Height
  • : 280
  • ⤷ Number of Handles
  • : 3
  • ⤷ Number of Outlet
  • : 3
  • ⤷ Outlet Connection
  • : 3 x 1/2" BSP Female
  • ⤷ Diverter Included
  • : Yes
  • ⤷ Orientation
  • : Portrait, Landscape
  • ⤷ Plumbing Option
  • : Concealed
  • ⤷ Building-in Depth Required
  • : 80
  • ⤷ Cartridge Included
  • : Yes
  • ⤷ Cartridge Type
  • : Thermostatic
  • ⤷ Separate Flow and Temperature Controls
  • : 3 Way

Total: £541.50 6 Working Days Approx QS Supplies

3 Features Included In This Product Explained



A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.

Low Water Pressure

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.

WRAS Approved Product

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
