Bristan Prism Thermostatic Shower Valve Recessed 3-Handle, 2-Outlet Diverter + Shut-off Control

Bristan Prism PM2 SHC3DIV C Details

Suitable for all plumbing conditions and both low and high water pressure system, this elegantly appealing Bristan Prism Thermostatic 2 Control Shower Valve with 2 Outlet Diverter will endow you with endless delightfully refreshing showering moments. Produced from best quality brass under strict quality control, this aqua beauty is supplied with metal backplates and handles. It comes with a ceramic disc valve for ensuring uniform water flow and smooth operation. This WRAS approved unit will conveniently fit in 35mm cavity space, comes with a maximum hot water temperature of 80°C and is backed by a five-year manufacturer guarantee.

The manufacturing code of this product is: PM2 SHC3DIV C.
It comes in an attractive chrome finish.
Deck mounted installation.
No of controls: 3.
Shower type: dual control.
Maximum hot water temperature: 65°C.
Maximum static pressure: 10 bar.
Size of baseplate in [mm]: 165mm x 355mm [Width x Height].
Size of baseplate in [cm]: 16.5cm x 35.5cm [Width x Height].
Inlet centre: 150mm - (15cm).
Suitable for all plumbing systems, ideally balanced.

Requires a minimum of 0.2 bar to a maximum of 0.5 bar of water pressure.
Connection inlet: 15mm compression.
Connection outlet: 15mm compression.
This shower valve has been designed to fit in any UK wall cavity and, therefore, only needs a 35mm deep cavity space.
Fitting depth, including plasterboard and tiles, is: 45mm - 75mm (4.5cm - 7.5cm).
The minimum cold water supply temperature is 4°c.
The maximum hot water supply temperature is 80°c.
Fully serviceable from the front.
Integral two-outlet diverter and single-stop valve.
Metal back plate and handles for added durability.
Refer technical diagram for technical dimensions.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Inlet Centres
: 150
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes

⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 165
⤷ Backplate Height
: 355
⤷ Number of Handles
: 3
⤷ Number of Outlet
: 2
⤷ Diverter Included
: Yes
⤷ Orientation
: Portrait
⤷ Plumbing Option
: Concealed

Total: £266.20 2 Working Days Approx QS Supplies

7 Features Included In This Product Explained

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

Family Safe

This feature corresponds with the Thermostatic mechanism and automatic safety stops, preventing running water from getting either too hot or too cold.

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

3 Outlets 2 On

There are three outlet connections, out of which any two can be used simultaneously.

Drenching

Drenching in Bristan showers means these showers soak you thoroughly, giving you the most indulgent showering experience.

Diverter

A diverter, specifically in bath-shower combos, redirects the water flow from the bathtub spout to the showerhead. You can activate it using the nozzle in the bath shower mixer tap.
Read more...

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

Reviews & Ratings

By: Nick From : BRIGHTON Overall Rating: Date: February 21, 2023 Exactly what we were looking for. High quality product

After having a poor-quality product installed and used for a few years, I finally took the opportunity to upgrade to a better unit. I needed a vertical unit with two outlets, and this exactly fits the bill. I also prioritised the need for it to be a good brand, and I was not disappointed by this Bristan unit. It looks great, feels solidly made and has actually allowed us to change the temperature when taking a shower - not just crazy hot or freezing cold. I would definitely recommend it.

Helpful?
