Dq Heating Delta Stainless Steel Vertical Radiator


RRP: £759.60


5 Working Days Approx.

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Product Variants
Select Finish Step 1
Select Height Step 2
Select Width Step 3
SKU Code: QS-V49600

MFC Code: DELTA-160/4-B

DQ Delta DELTA-160/4-B Details

DQ Heating Delta Stainless Steel Vertical Radiator is the most stylish and the finest solution for spreading warmth and comfort. It will amaze you with its practical and smooth functioning. Made to order from Stainless Steel, it comes with an attractive and easy-to-maintain brushed finish or alternately polished steel finish. It features three sections and a single row of flat-fronted tubes for a contemporary look. Convenient to install, use and maintain, it is covered by a guarantee of 25 years against any unlikely manufacturing defect. It's also an excellent heater for huge living spaces you'll be able to, and it won't take up much time in maintenance to bring a great atmosphere to any room.

Key Features
  • Manufactured from stainless steel
  • 25 years of guarantee from the manufacturer
  • Different finishes available: Brushed, Polished
  • Available heights: 1600mm, 1800mm, 2000mm.
  • Available widths: 230mm, 410mm.
  • 1/2 inch flow and return connection.
  • Test pressure: 6 Bar.
  • Maximum operation pressure: 4 Bar.
  • Maximum working temperature: 95ºC.
  • Wall to pipe centres: 43mm - (4.3cm).
  • Wall to front face: 68mm - (6.8cm).
  • The valves shown in the image are not included.
  • The image shown is for illustration purposes only.
  • Download the Installation Instruction PDF File from the Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Brushed Stainless Steel
  • ⤷ Shape
  • : Straight
  • ⤷ Warranty/Guarantee
  • : 25 Years
  • ⤷ Material
  • : Stainless Steel
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Height
  • : 1600
  • ⤷ Orientation
  • : Vertical
  • ⤷ BTU Output
  • : 2155
  • ⤷ Watts
  • : 631
  • ⤷ Valves Included
  • : Sold Separately

Additional Info & Downloads

Download PDF Download the Installation Instruction Pdf File

Technical Images

Total: £549.07 5 Working Days Approx QS Supplies

2 Features Included In This Product Explained

BTU Output

BTU Output

It is the short form of a British thermal unit (BTU or Btu) and is defined as the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit. It is a standard unit against which radiator efficiency is measured.

Watts Output

Watts Output

Unit of power to measure electric current.

You've Selected which adds to a total of

Reviews & Ratings

Rate this Item.:

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Graeme Asked :

Is the DQ Delta vertical radiator OK to use on an open vented heating system, with a conventional boiler? The reason I ask is that some other manufacturers specify that their vertical radiators are only suitable to be fitted to pressurised, closed or sealed systems with combi boilers.

Answered By QS Team Answered by the QS Technical Team

Thank you for your enquiry. We can advise that the Delta will be suitable for your use so long as the system is balanced out on the PRV. I hope this helps.
