Duravit D-Code 650mm Close Coupled Pan Only

Duravit D-Code Details

MFC: 21180900002|0940150004

Create a surprising statement with this sensationally designed D-Code Close Coupled Toilet. Cleverly designed by Sieger Design, this toilet comes with dual flushing cistern and is compatible with seat and cover available separately, including stainless steel hinges. This toilet is a modern classic toilet with a cistern that adds style to any bathroom. Having a gently round rectangular style that is popular among users in modern homes, the washdown model in pristine white is a vision to behold and comforting in use. The floor standing model comes with water saving 6-litre flush installation, and is backed by five years of warranty from the manufacturer.

Key Features

✔Designed by Sieger Design
✔Water-Saving 6-Litre Flush
✔Five Years of Warranty from the Manufacturer

Product Includes: WC Pan and Cistern
The Manufacturing Code of this Product is 21180900002|0940150004
Washdown Model
Size [mm]: 355 x 650 x 385mm [Width x Depth x Height]
Size [cm]: 35.5 x 65 x 38.5cm [Width x Depth x Height]
Fixings Included
Optional Product:
With HygieneGlaze
Toilet Seat and Cover
Connector for Horizontal or Vertical Outlet
Conversion Set
Toilet Seats Shown in the Image is Not Included

Info / Size (mm)

Toilet
Width: 385 mm
Projection: 650 mm
Height: 775 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: White
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Contemporary
⤷ Installation Type
: Floor Mounted
⤷ Water Saving
: Yes
⤷ Pan Width
: 355
⤷ Pan Height
: 385
⤷ Toilet Overall Height
: 775
⤷ Projection (Depth)
: 601-650

⤷ Cistern Width
: 385
⤷ Cistern Type
: Close Coupled
⤷ Cistern Lever Or Button Placement
: Top
⤷ Outlet
: Horizontal or Vertical
⤷ Configuration
: Bowl Only
⤷ Seat Included
: Sold Separately
⤷ Bowl Shape
: Elongated
⤷ Seat Post Hole Centers
: 170
⤷ Outlet Diameter
: 102
⤷ Base to centre of outlet
: 185

Additional Info & Downloads

Download the Mounting Instruction Pdf File

Add-Ons

Toilet Seat And Cover

Compatible Toilet Seat And Cover Available As An Optional.

No Option Selected
OP-165900 - Stainless Steel Hinges Without Automatic Closure + £72.38
OP-165901 - White Plastic Hinges With Automatic Closure + £111.80

Vario Connector Set

Vario connector set is for a horizontal or vertical outlet with an adjustable length from 70mm to 170mm. Vario connecting bend is for vertical outlet With an adjustable length from 160mm to 200mm. Please Note: The image shown is for illustration purpose only.

No Option Selected
OP-38507 - Vario Connecting Bend For Vertical Outlet Ø90m + £32.75
OP-38506 - Vario Connector Set For Horizontal And Vertical Outlet - Length Adjustable - Ø110m + £56.53

Conversion Set

Conversion set for the back supply of toilet, consisting of angle valve, connecting pipe and one blind plug with counter nut. Please note: The image is for illustration purpose only.

No Option Selected
OP-33312 - Chrome Conversion Set For Back Supply + £41.26

Duravit D-Code 650mm Close Coupled Toilet

£228.10

RRP: ~~£345.60~~

STOCK AVAILABLITY: 7 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

Vertical Outlet

It is a toilet where the plumbing exits through the floor. In certain scenarios, these toilets may need to be installed a few inches higher than the surrounding floor to accommodate the plumbing.

Optional: HygieneGlaze

DURAVIT's toilet, basin and urinal ceramic HygieneGlaze removes 99.9% of germs and pathogens without any chemicals - setting a new standard in toilet hygiene.

Washdown Model

A washdown toilet uses the weight of the water and gravity to push out the toilet waste from the toilet bowl. The washdown toilet is designed with a short and wide trapway, so that waste can quickly enter the trapway using just the force of water from the tank. A washdown model includes a push-button flush and has a skirted design with a smaller water surface area and a short trapway and can easily handle heavy loads without getting clogged.

Reviews & Ratings

By: dave From : BURY ST. EDMUNDS Overall Rating: Date: June 15, 2015 toilet

very good product.......but water supply option only on one side of cistern.

Helpful?

Quality:

Style

Value for Money

Questions & Answers

Submit Your Questions 4 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

John Asked :
Hi, we have an outlet on the floor that is 170mm (centre) from the wall. I've been looking for a bottom outlet toilet with little joy for this measurement. Reviewing this toilet, it seems to show that a back outlet with a certain connector can be used to fit my situation. Can you please confirm if I am correct and if this toilet will fit into an outlet 170mm from the wall?

Answered By QS Team

Please refer to the attached technical image. As you can see from the provided technical drawing, you will have a 215mm space between the wall and outlet with the additional OP-38506 - Vario Connector Set For Horizontal And Vertical Outlet - Length Adjustable - 0014220000 given as optional; you will be able to convert your outlet to fit. We would recommend the connector set over the connector bend, as the set can be adjusted for the length you require.

Was this answer helpful?

Sara Asked :
We currently have an S-trap toilet with a waste pipe coming up from the floor and want to know if this would be compatible. If so, what exactly do we need to order, please? Also, we want to order an Old London corner sink unit and want to know what type of tap and waste would be compatible. Thanks

Answered By QS Team

We believe the 21180900002 will not have enough room in the back to accommodate a waste pipe from the floor.

Was this answer helpful?

Tanya Asked :
How wide is the gap for the soil stack at the back of this toilet? Would it be able to fit over a cast iron soil stack that comes up from the floor? The soil stack is approx 140mm wide (total outer diameter) and set back 30mm from the wall. If you have more detailed diagrams, e.g. CAD, I would be most grateful if you could send them to me.

Answered By QS Team

Regarding the D-Code pan, 211809 00002 cannot be fitted to a cast iron soil stack as this pan is straight back to the wall. The pan you would need is the D-Code 211109 00002; this is a close-couple open-back pan. The soil stack gap is 135mm.

Was this answer helpful?

Lawrence Asked :
What side inlet pipe for the cistern?

Answered By QS Team

The inlet is on the bottom left.

Was this answer helpful?
