Vado Elements Air Chrome Mono Kitchen Sink Mixer Tap

Vado Elements ELA-150S-C/P Details

For an inviting and glamorous look, complement your kitchen sink with Elements Air Mono Sink Mixer Tap, manufactured by Vado. The contemporary sink faucet with a swivel spout stylises your sink and turns it into an adorable fixture.

The curvy spout sits on a tubular, solid base and is worked by a single side lever handle. This deck-mounted creation is supplied with a water-flow straightener and aerator, providing enhanced performance. It comes loaded with unique features that make it priceless. It is guaranteed for 15 years by the manufacturer against any manufacturing defects.

The manufacturing code of this product is ELA-150S-C/P.
Suitable for deck-mounted installation.
Requires minimum 1.0 bar water pressure.
Suitable for high water pressure system.
Size [mm]: 100mm x 176mm x 265mm [Width x Depth x Height].
Size [cm]: 10cm x 17.6cm x 26.5cm [Width x Depth x Height].
The centre of the inlet to the centre of the outlet is 140mm (14cm).

Ceramic cartridge CAR-K35B.
2 x 1/2 inch nut x 400mm (40cm) flex pipe connections.
Deck mount drill hole diameter 32mm (3.2cm).
Refer to the technical drawing for complete size details.
Download the installation and maintenance instruction PDF file from the additional info section.
Fifteen years of guarantee from Vado against any manufacturing defects.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Range
: Elements
⤷ Handle Position
: Right
⤷ Tap Body Shape
: Round
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Swivel
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Disc Cartridge

⤷ Base To Spout
: 195
⤷ Spout Reach
: 135
⤷ Overall Height
: 265
⤷ Inlet Connections
: 1/2 Inch
⤷ Minimum Operating Pressure (Bar)
: 1
⤷ Handle Style
: Stick Handle
⤷ WRAS Approved
: Yes
⤷ Compliance/Approvals/Standard
: WRAS
⤷ Barcode
: 5052120103760
⤷ Product Type
: Kitchen Sink Mixer Tap
⤷ Tails
: Flexible
⤷ Water Filter
: Yes

Additional Info & Downloads

Download the Installation And Maintenance Instruction Pdf File

Total: £148.50 2 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Flow Straightener

A flow straightener, also called Honeycomb, is a fitting which directs the flow of water from the outlet in a way as to straighten the stream. They are generally not flow-regulated and differ in design from the pressure-compensating aerator.

Swivel-Spout

The respective apparatus is engineered with the ability to move sideways or at certain angles, which helps them cover a greater area than would be possible in a stationary position.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
