Stuart Turner Showermate TP Standard S2.0 Twin Black Shower Pump

Stuart Turner Showermate TP Standard S2.0 Twin Black Shower Pump.

• Manufacturing Code of this Item is 49085
• Suitable for Positive Head Applications
• High Quality Entry Level Plastic Pump Supplied with 15mm Anti-Vibration Hoses
• Quiet Operation
• WRAS-Approved Product
• Intermittently Rated
• Anti-Vibration Feet
• EPDM/Carbon/Al.Oxide Seal
• Pre-Wired with 1.5 metre Power Cable
• Designed to Boost the Incoming Hot and Cold Water Supply to an Individual Shower, Bath, Shower Mixer or Mixer Tap
• Despite Being an Entry Level Pump, Showermate TP will Help Improve Water Pressure to a Single Appliance and is Suitable for Positive Head Applications Only
• Boosting Hot and Cold Water Supplies to a Single Shower, Bath, Shower Mixer or Mixer Tap in Low Pressure Gravity Systems
• Suitable for Use where there is Already more than 1 litre/sec Flow From the Outlet(s) to be Boosted
• Features:
• Pump Type: Centrifugal
• Mechanical Seal: EPDM / Carbon / Al. Oxide
• Anti-Vibration Feet: Yes
• Inlet Strainer(s): Yes
• Flexible Hoses: 4
• Dry Run Protection: Yes
• Noise (dB(A)): 53
• Materials:
• Pump Body: Plastic
• Impeller: Plastic
• Performance:
• Maximum Head (Closed Valve): 2.0 bar (20 metres)
• Performance @ 9 l/min: 1.5 bar
• Performance @ 18 l/min: 0.9 bar
• Maximum Flow: 35 l/min
• Maximum Static Inlet Pressure: 10 metres
• Maximum Working Pressure: 300 kPa (3 bar)
• Maximum Ambient Air Temperature: 40°C
• Min / Max Water Temperature: Min 4°C / Max 65°C
• Flow Switch Sensitivity (Approx) 0.8 l/min
• Connections:
• Pump Connections: G3/4 male
• Flexible hoses:
• Connections: G3/4 Female x 15mm Push-In x 185mm Long (Inlet), G3/4 Female x 15mm Push-In x 175mm Long (Outlet)
• Motor:
• Type: Series Wound, Manual Reset Thermal Trip
• Duty Rating: Intermittent (S3) 30 mins on / 30 mins off @ 9 l/min
• Electrical:
• Power Supply / Phase / Frequency: 230 V a.c. / 1 / 50 Hz
• Current (Full Load): 1.5 Amps
• Power Consumption: 300 Watts
• Fuse Rating: 3 Amps
• Power Cable (Pre-Wired): 1.5 metres
• Physical:
• Enclosure Protection: IPX2
• Length: 250mm [25cm]
• Width: 97mm [9.7cm]
• Height (Excluding Hoses): 152mm [15.2cm]
• Weight (Including Fittings): 2.6Kg
• Refer to the Technical Diagram for Complete Technical Dimensions
• Download Product Data Sheet and Installation Instructions PDF from the Additional Info Section
