Grohe BauEdge Wall Hung Washdown Rimless Ceramic WC Pan - Alpine White - 360 x 535mm

Not Yet Rated No Rating

£99.00

RRP: £217.00
SKU: QS-V115073
Key Features
  • Washdown Model
  • Rimless Technology
  • Manufactured Using Vitreous China Material
  • 5-Year Warranty from the Manufacturer
Pay in 3-Interest Free Payments
Shipping

Shipping: £26.99

Stock Availability

Stock Availability:

3-4 Working Days Approx.

Grohe BauEdge Details

MFC: 39809000

Grohe BauEdge Wall Hung Washdown Rimless Ceramic WC Pan - Alpine White - 360 x 535mm

  • Manufacturing Code of this Product: 26075001
  • Easy Clean
  • It Comes in an Alpine White Finish
  • Size [mm]: 360 x 410mm [Width x Depth x Height]
  • Size [cm]: 36 x 41cm [Width x Depth x Height]
  • Projection: 535mm [53.5cm]
  • Horizontal Outlet
  • Installation Type: Wall-Hung
  • Bowl Height: Standard Height
  • Suitable for Concealed Cistern
  • CL1 5A + CL2 According to EN997
  • Water-Saving
  • Installation Type: Wall-Hung
  • Flush Volume: 3/5L
  • Refer to the Technical Diagram for Complete Technical Dimensions
  • Download the Installation Instruction PDF File from the Additional Info Section

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : BauEdge
  • ⤷ Colour
  • : Alpine White
  • ⤷ Warranty/Guarantee
  • : 5 Year
  • ⤷ Material
  • : Vitrous China
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall-Hung
  • ⤷ Toilet Overall Height
  • : 410
  • ⤷ Projection (Depth)
  • : 535
  • ⤷ Rimless Bowl
  • : Yes
  • ⤷ Flush Type
  • : Dual Flush
  • ⤷ Full Flush Volume in litres
  • : 5
  • ⤷ Half Flush Volume in litres
  • : 3
  • ⤷ Width
  • : 360
  • ⤷ Outlet
  • : Horizontal
  • ⤷ Height
  • : 410
  • ⤷ Fixing Holes Centre
  • : 180
  • ⤷ Barcode
  • : 4005176637094
  • ⤷ Distance from floor to centre of fixing hole
  • : 330
  • ⤷ Bowl Shape
  • : Square
  • ⤷ Product Type
  • : WC Pan
  • ⤷ Front Of Bowl To Centre Of Seat Holes
  • : 435
  • ⤷ Outlet Diameter
  • : 102
  • ⤷ Base to centre of outlet
  • : 230

Additional Info & Downloads

Download PDFDownload the Installation Instruction Pdf File

This item can also be found in:
£99.00
RRP: £217.00
Stock Availablity: 3-4 Working Days Approx
QS Supplies

4 Features Included In This Product Explained

Rimless

Rimless

A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards their edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Washdown Model

Washdown Model

A washdown toilet uses the weight of the water and gravity to push out the toilet waste from the toilet bowl. The washdown toilet is designed with a short and wide trapway, so that waste can quickly enter the trapway using just the force of water from the tank. A washdown model includes a push-button flush and has a skirted design with a smaller water surface area and a short trapway and can easily handle heavy loads without getting clogged.

Vitreous-China Material

Vitreous-China Material

Vitreous china is an innovative glass-based enamel coating applied to porcelain. This glazed coating makes the base material durable, denser, and very glossy. When ceramics are coated with vitreous enamel, the resulting product is called vitreous china. This enamel is created by applying heat to powdered glass.

Horizontal Outlet

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.
