Jaguar Artize VIC 1000mm Traditional Wall Hung Console Basin with Washstand

Jaguar VIC Details

MFC: VCS-WHT-503803|AVC-CHR-503783

Jaguar Artize VIC 1000mm Traditional Wall Hung Console Basin with Washstand.

Key Features

✔CE Approved
✔Anti-Germ Glazing
✔Manufactured using Ceramic-FFC Material
✔Compliance: EN 14688:2015 (E),EN 997 :2012+A1:2015
✔Warranty: 10-Year for Basin and 5-Year for Washstand Finishes from the Manufacturer

Choice of Basin Variations: 1 Taphole, 3 Taphole
Choice of Washstand Finishes: Chrome, Blush Gold, Bright Gold
Victorian Look and Elegant Design
Exclusive Design Basin and Washstand
Refer to the Technical Drawing for Size Details
Details of Basin:
Size [mm]: 1000 x 510 x 180mm [Width x Depth x Height]
Size [cm]: 100 x 51 x 18cm [Width x Depth x Height]
Outlet: Vertical
Tap Hole Diameter: Ø 35 ± 2 mm
Waste Outlet Hole Diameter: Ø 45 ± 3 mm
Accessories: Fixing, Rag Bolt, Overflow Hole and Cap Included
Soft Corner and Large Side Platforms and Compatible with Metal Frame
Horizontal Distance Between the Centre Line of the Tap Hole and the Centre Line of the Waste Outlet Hole ≤ 150 mm
Weight: 26.55 kg
Waste Shown in the Image is not Included
Details of Washstand
Material: Stainless Steel Frame
Comes with Towel Rail and Rack
Size [mm]: 825 x 425 x 850mm [Width x Depth x Height]
Size [cm]: 82.5 x 42.5 x 85cm [Width x Depth x Height]

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: VIC
⤷ Colour
: White
⤷ Weight in kg
: 26.55
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 10 Years Basin | 5 Years Washstand Finishes
⤷ Material
: Vitreous China
⤷ Theme
: Traditional
⤷ Projection (Depth)
: 510
⤷ Width
: 1000
⤷ Height
: 180
⤷ Fixings included
: Yes
⤷ Inner Bowl Width
: 470
⤷ Inner Bowl Depth
: 330
⤷ Distance rear edge to centre of waste hole
: 150

⤷ Fixing Holes Centre
: 280
⤷ Distance rear edge to centre of tap hole
: 50
⤷ Number of bowls
: 1
⤷ No. of Tap Holes
: 1
⤷ Tap Hole Position
: Center
⤷ Overflow Included
: Yes
⤷ Tap Hole Size
: 35
⤷ Barcode
: 5057199985729
⤷ Stand Included
: Yes
⤷ Stand Finish
: Chrome, Blush Gold, Bright Gold
⤷ Height With Stand
: 850
⤷ Stand Material
: Stainless Steel
⤷ Product Type
: Basin With Washstand

Technical Images

Jaguar Artize VIC 1000mm Traditional Wall Hung Console Basin with Washstand

1 TH - Basin

3 TH - Basin

Washstand

£807.10

RRP: ~~£1153.00~~

STOCK AVAILABLITY: 5 Working Days Approx

QS Supplies

3 Features Included In This Product Explained

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.

Stainless Steel Material

Stainless Steel is an iron alloy with anti-rust and anti-corrosive properties, unlike iron. Along with other metal alloys, it contains a minimum of 10.5% of chromium and less than 1.2% of carbon. This robust, hygienic, hard-wearing base material is popular in the construction of bathroom products.
