Joseph Miles Muro Deck Mounted Bath Mixer Tap

Muro TAP242L Details

Joseph Miles Muro Deck Mounted Bath Mixer Tap.

Suitable for medium water pressure systems.
Works on minimum 0.5 bar to maximum 5.0 bar water pressure.
Tap hole diameter: Ø32mm.
Cartridge type: Quarter turn cartridge.
Refer to the technical diagram for complete technical dimensions.
Download the installation instructions PDF from the Additional Info sections.
Features Of Tap Only:.
Weight: 1.96kg.
Inlet connection: 3/4 BSP.
Inlet centres: 180mm.
Base to spout height: 85.8mm.

Centre of inlet to centre of outlet: 106.5mm.
Size: 226mm x 150.5mm x 134.2mm [Width x Depth x Height].
Features Of Tap With Kit:.
Weight: 2.47kg.
Inlet connection: 3/4 BSP.
Outlet connection: 1/2 BSP Handset.
Inlet centres: 180mm.
Base to spout height: 85.8mm.
Centre of inlet to centre of outlet: 106.5mm.
Size: 226mm x 150.5mm x 134.2mm [Width x Depth x Height].

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Rotating
⤷ Range
: Muro
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome, Matte Black, Brushed Brass
⤷ Warranty/Guarantee
: Lifetime
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 2
⤷ Spout type
: Fixed
⤷ Valve/Cartridge Type
: Quarter Turn Cartridge

⤷ Base To Spout
: 85.8
⤷ Spout Reach
: 106.5
⤷ Inlet Centres
: 180
⤷ Overall Height
: 134.2
⤷ Width
: 226
⤷ Inlet Connections
: 3/4 Inch BSP
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Handle Style
: Lever Handle
⤷ WRAS Approved
: Yes
⤷ Barcode
: 5057199976277
⤷ Product Type
: Bath Mixer Tap

Additional Info & Downloads

Download the Installation Instructions Pdf File

Total: £112.48 5-7 Working Days Approx QS Supplies

3 Features Included In This Product Explained

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.

Quarter Turn

Operating these taps is almost effortless; it can be turned on and off by rotating the lever at 90 degrees. These taps have such low friction that they are perfect for people with arthritis, weak grip, the elderly and the young.
