QS Basics Accord Semi Flush To Wall WC Pan With Cistern

QS Basics Accord QSB-1786 Details

QS Basics Accord Semi Flush to Wall WC Pan with Cistern is a practical solution for contemporary bathrooms. It is created from the finest quality vitreous china in a strong and resilient yet comfortable-to-sit-upon design.

The optional soft close seat can prevent unpleasant slamming sounds. The cistern with a dual flush mechanism provides for long or short flushes depending on the nature of use, leading to water conservation and reduced utility bills. Just add a couple of new accessories with this unit, such as a toilet roll holder, to brighten up the space and make it feel fresh and new.

The manufacturing code of the product is QSB-1786.
Includes pan and cistern.
It comes in a white finish.
Overall Size: 380mm x 625mm x 800mm [Width x Projection x Height].
Pan Size: 370mm x 625mm x 407mm [Width x Projection x Height].
Cistern Size: 380mm x 145mm x 390mm [Width x Depth x Height].
Weight: 39kg.
The seat shown in the image is not included - sold separately.
Pan fixing kit - [Optional].

Refer to the technical drawing for more details.
Details For Pan:.
Type: open to a wall.
Round shape bowl.
Trap style: P trap.
Details For Cistern:.
Flush Capacity: 6/3L.
Plastic chrome plated push button.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Accord
⤷ Toilet Design
: Open Back
⤷ Colour
: White
⤷ Weight in kg
: 39
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Water Saving
: Yes
⤷ Pan Width
: 370
⤷ Pan Height
: 407
⤷ Toilet Overall Height
: 800
⤷ Projection (Depth)
: 625
⤷ Cistern Included
: Yes
⤷ Cistern Width
: 380
⤷ Cistern Height
: 390
⤷ Flush Type
: Dual

⤷ Full Flush Volume in litres
: 6
⤷ Half Flush Volume in litres
: 3
⤷ Flush Mechanism
: Push Button
⤷ Cistern Lever Or Button Placement
: Top
⤷ Outlet
: Horizontal
⤷ Configuration
: WC Pan With Cistern
⤷ Seat Included
: Sold Separately
⤷ Fixings included
: Sold Separately
⤷ Bowl Shape
: Round
⤷ Product Type
: Close Coupled Toilet
⤷ Cistern Depth (projection)
: 145
⤷ Seat Post Hole Centers
: 155
⤷ Front Of Bowl To Centre Of Seat Holes
: 430
⤷ Base width
: 245
⤷ Base Depth (projection)
: 390
⤷ Base to centre of outlet
: 185

Customise Your Product

Optional Soft-Close Toilet Seat

Compatible toilet seats are available as options. Please note: Images shown are for illustration purposes only.

No Option Selected
OP-235095 - Luxury D-Shape Top-Fix Soft Close Seat With Quick Release + £31.04

Optional Fixings

Compatible, fine quality fixing kit is available as an option. Please Note: The image shown is for illustration purpose.

No Option Selected
OP-235028 - WC Pan Fixing Kit + £11.83

Total: £118.03 5-7 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Vitreous-China Material

It is a compound of glass and silica-based materials applied as a coat on porcelain products such as WC pans, urinals, baths and basins to protect them from scratches and stains as an anti-vandal measure.

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

Optional: Quick Release Toilet Seat

The hinge on a regular toilet seat makes it challenging to clean in some areas. As a result, some areas build up with hairs, grime, and dirt over time. Fortunately, the invention of a quick-release toilet seat means you can keep your entire toilet clean. The hinge mechanism of these toilets allows you to remove the seat entirely, making it easier to wash the areas it covers on the toilet itself.

Optional: Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.
