Nuie Ravi Mono Dual Lever Deck Mounted Kitchen Mixer Tap

Nuie Ravi KRA305DL Details

Nuie Ravi Mono Dual Lever Deck Mounted Kitchen Mixer Tap is the perfect luxury mixer tap for use in premium spaces. The design is minimal, but the high arch covers more ground, even in a roomy kitchen sink bowl. The fixture is brass with a gorgeous finish, and you have the freedom to select one of the many available.

The transitional design makes it easy to include the mixer in different kinds of decor. On the base are two levers that control the water flow and temperature and feel pleasant to the touch. And the best part, you dont need high water pressure for the smooth working of the mixer; 0.5 bar of water pressure will do good.

Supplied with the handset, cartridge, mounting hardware, tap tails and fixing.
Height: 436mm (43.6cm).
Pipe size: 15mm (1.5cm) (1/2inch BSP).
Base to spout: 165mm (16.5cm).
Centre of the inlet to centre of outlet: 220mm (22cm).
Control type: Manual.
Suitable for deck-mounted installation.
Cartridge material: Plastic.

Ceramic disc technology for long life and smooth operation.
A high-end finishing touch to any kitchen.
Suitable for medium-pressure water system.
Requires a minimum of 0.5 bar of water pressure.
Flow Rates: 0.1 bar - 1.6, 0.5 bar - 3.1, 1 bar - 4.3, 2 bar - 6, 3 bar - 7.3.
Download the Installation Instruction and Customer Data Sheet PDF File from the Additional Info Section.
Refer to the technical drawing for more technical specifications.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Handle Position
: Left | Right
⤷ Range
: Ravi
⤷ Tap Body Shape
: Round
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years | 3 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 2
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes

⤷ Valve/Cartridge Type
: 1/4 Turn Ceramic Disc
⤷ Base To Spout
: 165
⤷ Overall Height
: 436
⤷ Width
: 132
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Flow Rates (l/min)
: 0.1 bar - 1.6 | 0.5 bar - 3.1 | 1 bar - 4.3 | 2 bar - 6 | 3 bar - 7.3
⤷ Handle Style
: Lever
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 5056678400975
⤷ Product Type
: Kitchen Sink Mixer Tap
⤷ Tails
: Yes

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instruction Pdf File

Total: £101.93 5-7 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.

Monobloc Tap

A Monobloc/Mono tap has a single control lever that adjusts the mix of hot and cold water supplies and the flow rate. A mixer tap has two separate controls for hot and cold water. Both work equally well, and your choice will come down to aesthetics and how many tap holes your sink has. Monobloc taps are a neater solution and more modern in appearance.
