Joseph Miles Duna Rimless Close Couple WC Pack

Joseph Miles Duna JMQS100522 Details

If you are looking for a classy WC Pack for your establishment, look no further than the Joseph Miles Duna Rimless Close Coupled WC Pack. It can be a good choice for educational, hotels, leisure, and other commercial establishments. The fixture is made from vitreous China material for long-lasting use and comes together with a soft close seat. The flush operates using the Push button activation and carries a Lifetime guarantee for WC Pan and two years guarantee for toilet seats from the manufacturer. Pair it with one of our latest toilet roll holder designs and transform your bathroom area.

It comes in a white finish.
Width: 370mm.
Projection: 630mm.
Distance from soil pipe spigot to the wall: 194mm.
Flush operation: Push button.
Cistern inlet position: Left.
Coupling to soil stack: Straight out and straight down.
Supplied with soft close seat.
Finished in white to match existing sanitary-ware.
N/B, please allow a tolerance of +/-2% on dimensions over 75mm and a tolerance of +/-4% on dimensions under 75mm.

Refer to the technical diagram for the complete technical dimension.
Features of Open Back Toilet:.
Height: 825mm.
Cistern Depth: 135mm.
Lift off a seat for easy cleaning, top fix hinges.
The water-saving dual flush button gives 4L and 6L.
Features of Fully Shrouded Toilet:.
Height: 830mm.
Cistern Depth: 130mm.

Info / Size (mm)

Toilet
Width: 370 mm
Projection: 630 mm
Height: 825/ 830 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Duna
⤷ Toilet Design
: Open Back, Fully Shrouded
⤷ Colour
: White
⤷ Warranty/Guarantee
: Lifetime on sanitary ware 2 years on seat and hinges
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Installation Type
: Floor-Mounted
⤷ Pan Width
: 370
⤷ Pan Height
: 425
⤷ Toilet Overall Height
: 825
⤷ Projection (Depth)
: 630
⤷ Rimless Bowl
: Yes
⤷ Cistern Included
: Yes
⤷ Cistern Width
: 310
⤷ Cistern Height
: 400
⤷ Flush Type
: Dual Flush

⤷ Full Flush Volume in litres
: 6
⤷ Half Flush Volume in litres
: 4
⤷ Flush Mechanism
: Push Button
⤷ Cistern Lever Or Button Placement
: Top
⤷ Seat Included
: Yes
⤷ Seat Type
: Soft Close
⤷ Seat Finish
: White
⤷ Barcode
: 5057199967503
⤷ Bowl Shape
: Elongated
⤷ Product Type
: Close Coupled WC Pack
⤷ Cistern Depth (projection)
: 135
⤷ Seat Post Hole Centers
: 155
⤷ Base width
: 240
⤷ Base Depth (projection)
: 540
⤷ Outlet Diameter
: Ø102
⤷ Base to centre of outlet
: 180

Total: £253.58 5-7 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Push-Button Flush Valve Cistern

Toilets with push-button flush valves are usually dual-flush toilets. One button triggers a liquid, and the other is for solid flushes. Additionally, since these valves are smaller than levers, they use less water than traditional toilets.

Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.

Dual-Flush

A toilet with a flushing mechanism with two different buttons for flushing solid and liquid waste, thereby saving water.

Vitreous-China Material

It is a compound of glass and silica-based materials applied as a coat on porcelain products such as WC pans, urinals, baths and basins to protect them from scratches and stains as an anti-vandal measure.
