Bristan Aster Chrome Bath Mixer Tap

Aster AST BF C Details

Enjoy and experience excellence by installing this Bath Mixer Tap from the house of Bristan. The product comes from the brands Aster range and is supplied in two models. It features a quarter-turn mechanism and is suitable for low and high pressure water systems. The chrome finish model, fitted with a quarter-turn ceramic disc cartridge, is guaranteed against all manufacturing defects for five years. It enjoys a whopping discount at our online store. It works effortlessly in both low and high water pressure. These taps are budget refreshes for the bathroom and can be used with compatible bathtubs.

Available Variations: Tap Only, Tap With Handset.
It comes in a chrome finish.
Suitable for deck-mounted installation.
Long life and easy to use 1/4 turn ceramic disc valves.
Height: 125mm - (12.5cm).
Depth: 160mm - (16cm).
Connection Inlet: 3/4 inch BSP.
Connection outlet: M24 flow straightener.
Number of tap holes: 2.
Valve/Cartridge type: 3/4 inch ceramic disc valves - 1/4 turn.
Maximum hot water temperature: 60°C.
Maximum static pressure (bar): 10 bar.

Flow type: single flow.
Suitable for low and high water pressure.
Require a minimum of 0.2 bar to a maximum of 5.0 bar of water pressure.
Download the Installation Instruction PDF File From The Additional Info Section.
Refer to the technical diagram for the complete technical dimension.
Features Of Tap Only:.
Spout Reach: 116mm - (11.6cm).
Base To Spout: 60mm - (6cm).
Features Of Tap With Handset:.
Spout Reach: 118mm - (11.8cm).
Base To Spout: 62mm - (6.2cm).
This bath shower mixer includes a hose and a single-function handset.

Info / Size (mm)

Taps
Pipe Center: 116, 118 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Aster
⤷ Water Activation
: By Lifting/Tilting
⤷ Tap Body Shape
: Round
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck-Mounted
⤷ No. of Holes Required
: 2
⤷ Valve/Cartridge Type
: Ceramic Disc Valve

⤷ Base To Spout
: 60
⤷ Spout Reach
: 116
⤷ Overall Height
: 125
⤷ Width
: 230
⤷ Inlet Connections
: G 3/4 Inch
⤷ Minimum Operating Pressure (Bar)
: 0.2
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes
⤷ Barcode
: 5014868070469
⤷ Product Type
: Bath Mixer Tap

Additional Info & Downloads

Download the Installation Instruction PDF Pdf File

Total: £56.89 2 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Luminance Chrome

It is a hard-wearing chrome plating which is salt-tested and scratch-proof for durable, long-lasting use.

Precise Glide

It comes incorporated with ceramic cartridges for long life with precise control for smooth, leak-free use.

Secure Fix

The design features metal fixings that secure your tap, preventing any movement or rotation during use.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
