Ideal Standard Concept Cube 500mm White 1 Tap Hole Countertop Basin

Ideal Standard Concept E501301 Details

The most striking feature of Ideal Standards Concept Cube Countertop Basin is its perfectly proportioned and contemporary compact look. Designed by Robin Levien, it comes with 1 tap hole and is suitable for use in the home and commercial locations. Its stylish rectangular shape makes an immediate visual impact. Constructed from high-grade Vitreous China, its durability is peerless, makes an excellent acquisition and comes with a lifetime guarantee. You have the option to select from 2 convenient sizes. Easy to install and maintain, it is available at QS Supplies at an excellent price.

Available in 2 sizes - 500mm, 580mm.
1 tap hole with overflow.
Designed by designer Robin Levien.
Ideal for domestic and commercial use.
Self-rimming for drop-in installation as per template supplied and joint sealed with waterproof sealant [not supplied].
They are frequently used in education, healthcare, hotels, office, pubs, clubs, residential, retail, sports and leisure applications.
For complete size details, please refer to the technical drawing.
Specification For 500mm Basin:.
Size [mm]: 500mm x 390mm x 175mm [Width x Depth x Height].
Size [cm]: 50cm x 39cm x 17.5cm [Width x Depth x Height].

Capacity: 3.1 litres.
Weight: 10.25 kg.
Specification For 580mm Basin:.
Size [mm]: 580mm x 430mm x 175mm [Width x Depth x Height].
Size [cm]: 58cm x 43cm x 17.5cm [Width x Depth x Height].
Capacity: 4.0 litres.
Weight: 11.50 kg.
Bottle trap [Optional].
Tap, waste, and worktop shown in the image are not included - sold separately.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Concept
⤷ Colour
: White
⤷ Weight in kg
: 10.25
⤷ Shape
: Rectangular
⤷ Country of Origin
: EU
⤷ Warranty/Guarantee
: Lifetime
⤷ Material
: Vitreous China
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Projection (Depth)
: 390
⤷ Width
: 500
⤷ Height
: 175

⤷ Inner Bowl Depth
: 265
⤷ Distance rear edge to centre of waste hole
: 200
⤷ Distance rear edge to centre of tap hole
: 70
⤷ Depth of tap platform
: 125
⤷ Number of bowls
: 1
⤷ No. of Tap Holes
: 1
⤷ Tap Hole Position
: Centre
⤷ Overflow Included
: Yes
⤷ Compliance/Approvals/Standard
: Washbasin to BS EN 14688 & BS EN 31
⤷ Barcode
: 5017830447276
⤷ Product Type
: Inset Basin

Customise Your Product

Waste & Trap

Strong and durable waste or traps from Armitage Shanks - Ideal Standard to choose from options. Please note: The image shown is for illustration purpose only.

OP-56816 - 1.25 Inch Multi-Purpose Outlet Plastic Bottle Trap + £23.96
OP-61444 - 1.25 Inch Chrome Contemporary Metal + £144.00

Total: £183.30 3-4 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Vitreous-China Material

It is a compound of glass and silica-based materials applied as a coat on porcelain products such as WC pans, urinals, baths and basins to protect them from scratches and stains as an anti-vandal measure.

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

SELF RIMMING

A self-rimming sink is installed using the rimming lip by transferring its weight to the countertop. Such sinks are aesthetically pleasing and can take on a lot more weight. The design has no hidden crevices, making it easy to keep the sink and rim clean. Removing an old one and installing a new one is also an easy process with this kind of sink.
