Beo Slimline 90mm Wc Frame With Dual Flush Cistern


RRP: £399.00


6 Working Days Approx.

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Flush Plate
Key Features
  • Comes with front access to cleaning and maintenance
  • Includes both straight and angled soil pipe
  • WRAS Approved product
  • Frames are supplied complete with extension bolt set and quick fix nuts
SKU Code: QS-V98070


Beo Slimline BEO-SLFRAME Details

Beo Slimline 90mm WC Frame with Dual Flush Cistern has a width of 580mm, Depth of 90mm and height of 1180mm. It comes with a dual flush cistern with 80mm depth and flush capacity of 6L and 3L for full and a half respectively. Cleaning and maintenance are accessible via the front access. It is provided with a soil pipe and a complete pre-wall installation bolt kit. WRAS Approved product is now available at an unbeatable price from qs supplies.

  • Size of frame In [mm]: 580mm x 90mm x 1180mm [Width x Depth x Height].
  • Size of frame In [cm]: 58cm x 9cm x 118cm [Width x Depth x Height].
  • Dual flush cistern included.
  • Cistern Depth: 80mm - (8cm).
  • Cistern flush capacity: Full Flush 6L and Half flush 3L (standard).
  • Cistern can be modified for flush capacity to Full Flush 4.5L and Half flush 3L.
  • Compatible flush plate available [Optional].
  • Supplied with complete pre-wall installation bolt kit adjustable from 90mm - 110mm depth.
  • Cover all aspects of sanitary-ware and brass-ware installation.
  • Eliminates the need for unsightly pipe-boxing and exposed pipes.
  • The wall bracket and top of the frame are designed for easy shelf installation.
  • Download the Installation Instruction PDF File From The Additional Info Section.
  • Refer technical drawing for more technical details.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Colour
  • : Blue
  • ⤷ Cistern Included
  • : Yes
  • ⤷ Flush Type
  • : Dual Flush
  • ⤷ Full Flush Volume in litres
  • : 6
  • ⤷ Half Flush Volume in litres
  • : 3
  • ⤷ Width
  • : 580
  • ⤷ Depth
  • : 90
  • ⤷ Height
  • : 1180
  • ⤷ Fixings included
  • : Yes
  • ⤷ Flush Plate Included
  • : Sold Separately

Additional Info & Downloads
