Duravit DuraSystem Urinal Frame For Concealed Flushing Valve, WD3004000000

Finish the installation of your concealed flush urinal with the reliable and strong Duravit DuraSystem Urinal Frame For Concealed Flushing Valve. The self-supporting frame is made from strong, galvanised metal and is designed to support urinals that are connected to the system from behind. The unit has a galvanised, self-supporting frame and is built from reliable metal/plastic. The product is well suited for panelling using plasterboard and is compatible with installation into drywall while also being compatible with electronic and mechanical actuator plates.

The Manufacturing Code of this Product is WD3004000000
Suitable for Urinals with a Water Connection from Behind
Download the Mounting Instruction PDF
Refer to the Technical Drawing for Complete Size Details
Features Of Urinal Frame - WD3004000000:
Powder-Coated Frame
Size [mm]: 500 x 1148mm [Width x Height]
Size [cm]: 50 x 114.8cm [Width x Height]
Traverses Adjustable in Height
Height Adjustable Feet 0-240mm
Weight: 12 Kg
Mains Terminal 100-240 V AC 50/60 Hz
Compatible with Drywall Construction
Cross Bar with Concealed Plastic Housing and Quick-Fitting System
Suitable for Panelling with Plasterboard
Traverse with Flush-Mounted-Plastic Housing and Quick Fitting
Metric Tear and Centre Tear Marking
Suitable for Mechanical/Electrical Actuator Plates
For Urinals with a Water Inlet from the Rear
Cross Beams are Adjustable in Height Without the Need for Tools
Suitable for Mechanical/Electronic Exposed Flushing Valves
Requirements of the Leading Standards of Noise Protection DIN 4109 and VDI 4100 Can be Achieved [In Combination with Noise Reduction Set [WD6015 000 000]
Concealed Plastic Housing:
Universal Plastic Housing for Urinal Control, Including Construction Cover
Mains Connection Terminal: 100 – 240V AC 50/60 Hz
Scope Of Delivery:
Two Cover Caps
Hanger Bolts M8
Reinforced Hose R1/2
Drain Pipe Clip DN50
HT- Connection Bend DN50/40
Inlet Connector G1/2 A with Lip Seal
Sound-Insulated Elbow Tap Connector G1/2
Mounting Accessories for Lightweight Construction
Mounting Accessories for a Single Installation
Optional Product:
240mm Extension Set Available - WD6012000000
Noise Reduction Set for Single Installation - WD6015000000
Suitable Actuator Plates

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: White
⤷ Country of Origin
: Germany
⤷ Material
: Metal/Plastic

⤷ Width
: 500
⤷ Height
: 1148
⤷ Flush Plate Included
: Sold Separately

1 Features Included In This Product Explained

Drywall

Drywall, or wallboard, also called plasterboard or gypsum board, is a common building material used in interiors for constructing walls and ceilings. Drywall is gypsum plaster in the middle with layers of paper or fiberglass mats on either side. Drywalls do not need mortar or plaster. The gypsum core is rigid, and the other surface is smooth.
