Grohe Grohtherm Thermostatic Chrome Mixer For 1 Outlets With Shut Off Valve

Grohe Grohtherm 24078000 Details

The Grohe Grohtherm Thermostatic Mixer for 1 Outlet with Shut Off Valve is supplied without the roughing-in-set required for installation. However, a compatible Rapido Smart Box can be included separately if chosen as an option. Complete with a turbo stat compact cartridge with a wax thermoelement; this product also includes built-in non-return valves as well as dirt strainers. Boasting a safety stop plus an optional temperature limiter set at either 43 or 46 degrees Celsius, this model is certain to provide a safe and comfortable flow of water running through it. Combine it with a contemporary riser rail kit to enjoy a relaxing shower.

The manufacturing code of this product is 24078000.
It comes in an attractive chrome finish.
Wall escutcheon with GROHE QuickFix (covered escutcheon- and shaft sealing, covered fixing).
Safe stop safety button at 38°C (calibration required).
Safe stop Plus optional temperature limiter at 43°C or 46°C included.
Ceramic stop valve, 120°.
Flow performance:.

Outlet B = 27 l/min.
Outlet C = 30 l/min.
Supplied without roughing-in-set.
Rapido Smart box: 35600000 (Optional).
Refer to the technical diagram for the technical dimension.
Download the Installation Instruction PDF File From The Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Shape
: Square
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Handle Style
: Knob

⤷ Depth
: 43
⤷ Temperature Control
: Thermostatic
⤷ Backplate Width
: 158
⤷ Backplate Height
: 158
⤷ Number of Handles
: 2
⤷ Plumbing Option
: Concealed

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £261.92 2 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Grohe TurboStat

It is a revolutionary thermostat shower technology which is the fastest and most accurate on the market today. The increased sensitivity of the thermoelement now enables these thermostats to react to water pressure changes at much quicker speeds and provide water at the desired temperature in a fraction of a second while maintaining it for the entire shower.

GROHE QuickFix Plus®

This technology offers faster, easier and hassle-free installation that reduces installation time by up to 50%. The process is simplified by simply reducing the number of elements required for fitting, allowing a swifter fix. This technology ensures that Rapid SL frames are far quicker and simpler to install. In this tool-free process, the inspection shaft simply clicks into place, which along with two screws, is all you need to install the fixing frame. The wall brackets are also easier and faster to fit than earlier versions. This automatically means lower costs and better value for the customer.

Grohe SafeStop & SafeStop (Plus)

It is an excellent safety feature for homes with children, preventing scalding accidents. This button is factory set at 38°C, which prevents users from increasing the water temperature beyond a specific limit. When required, higher temperatures can be selected by pushing the button. Additional safety is provided by the SafeStop Plus limiter, which ensures that the temperature does not exceed 43°C.

Grohe StarLight

It is a durable, long-lasting surface that ranges from matte to shiny, like a diamond. This finish or long-lasting surface quality of every product from this manufacturer keeps it looking as good as new for years to come. The pledge of continuous improvement has refined this unique plating process to bring you a surface polish that is robust and immaculate and finds no match anywhere across the globe. A key contributing factor is rigorous quality control measures and regular healthy investments.

Escutcheon

These are also called flanges or cover plates and are available to match the fitting of showers, taps and toilets. Escutcheons come in various sizes, styles and finishes and can easily be replaced.

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Shung Asked :
Hi, I want to purchase this. What else do I need to buy to connect to Grohe New Tempesta 100 Shower Rail Set 3 Sprays? Is there an extra valve outlet to be installed to connect the shower hose to?

Answered By QS Team
