Crosswater MPRO Crossbox 2500 3 Outlet Valve

Crosswater MPRO PROCB2500LBPC+ Details

The Crosswater MPRO Crossbox 2500 3 Outlet Valve is suitable for use with any high-pressure water system and fits in especially well to any modern bathroom design. Crafted for wall-mounted installation from incredibly durable, high-quality materials; this product comes in the users choice of one of four fashionable finish options and is intended for recessed installation as well. Complete with built-in, Easy switch thermostatic module included, this product allows for fast and simple flow reversal in the case of the plumbing being installed in the improper placement.

Key Features

✔Available in 6 finishes
✔WRAS approved
✔Cartridge - Thermo cartridge + flow control/s
✔Fifteen years warranty against any manufacturing defects
✔Super slim 60mm minimum installation depths require reduced solid wall preparation for quicker installation time

Wall-mounted installation.
Thermo type: Recessed.
Size of back plate: 130mm x 180mm [Width x Height].
Front or rear mounting options increase ease of installation and flexibility.
Built-in, the easy-switch thermostatic module allows for simple, quick flow reversal if feeds are plumbed in the wrong way round.
Improved flow dynamics allow 90-degree elbows to be fitted directly to outlets to create a more compact piping footprint.
Simple 2 stage fixing allows installation of in-wall components and final trim separately reducing possible on site damage.
'Flush-block' testing plate included for easy pressure testing.

Easy fix 2nd stage trim sets reduce installation times.
CrossBox Universal Box not included.
CrossBox Universal Box - CROSSBOX [Optional].
Suitable for high water pressure system.
Required minimum 1.0 bar or above water pressure.
Download Installation Instruction PDF File from the Additional Info Section.
Refer to the technical diagram for the complete technical dimension.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Inlet Connections
: G1/2 Inch
⤷ Minimum Operating Pressure (Bar)
: 1.0
⤷ Handle Style
: Lever
⤷ WRAS Approved
: Yes

⤷ Backplate Width
: 130
⤷ Backplate Height
: 180
⤷ Number of Handles
: 2
⤷ Number of Outlet
: 3 Outlet
⤷ Diverter Included
: Yes
⤷ Orientation
: Vertical
⤷ Plumbing System Compatibility
: Concealed
⤷ Cartridge Type
: Thermo Cartridge + Flow Control/s
⤷ Diverter Type
: 3 Way

Additional Info & Downloads

Download the Valve Installation Instruction Pdf File Download the Crossbox Installation Instruction Pdf File

Technical Images

Crosswater MPRO Crossbox 2500 3 Outlet Valve

Total: £356.07 2 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

Reviews & Ratings

By: Ersoy From : LONDON Overall Rating: Date: November 20, 2020 Mixer Tap oozing Quality and Looks

As I was refitting a complete bathroom, I thought for once I would go the extra mile and buy something that looks better than standard and has a reputable name behind it. I must say I was not disappointed when the items arrived, they have the look of quality and build.
