Hudson Reed Fusion 1200mm Full Depth Floor-Standing Vanity Unit And Basin

Hudson Reed Fusion CBI134 Details

The Hudson Reed Fusion Full Depth Floor-Standing Vanity Unit and Basin is large and spacious made up of 2 units of 600mm width to provide several different types and sizes of cabinet spaces and an ample storage area. Available in several different finish options to choose from, this product is supplied to the user rigid to ensure fast and simple installation. Designed with more than one handle finish to pick from as well, this product also comes with the fixings required for proper installation and is crafted to be a sturdy, floor-standing unit from top to bottom.

Key Features

✔Cabinet Material Finish: MFC Painted Gloss
✔Fascia Material Finish: MDF Painted Gloss
✔Construction method: Cam and Wood Dowel
✔FSC Certified
✔Five-year guarantee from Hudson Reed against manufacturing defects.

Choice of different finish - [Optional].
Overall Size [mm]: 1205mm x 360mm x 904mm [Width x Depth x Height].
Overall Size [cm]: 120.5cm x 36cm x 90.4cm [Width x Depth x Height].
Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section.
Refer technical drawing for more specification.
Details For Unit:.
Suitable for floor-standing installation.
Two units of 600mm (60cm) Width supplied.
Size [mm]: 1200mm x 353mm x 864mm [Width x Depth x Height].
Size [cm]: 120cm x 35.3cm x 86.4cm [Width x Depth x Height].
2 Soft closed doors and 1 Drawer in each unit.
One internal shelf in each unit.
Hinge type: 95 Degree Clip-On Soft Close.
Cabinet Thickness: 16mm (1.6cm).
Fascia thickness: 18mm (1.8cm).
Fixing included.
Supplied Rigid.
Full-depth offers ample storage capacity.
Contemporary Wrap over handle in Satin nickel finish included.
Choice of other handles in different finishes available - [Optional].

Details For Polymarble Basin:.
It comes in a white finish.
Manufactured using poly marble material.
Size [mm]: 1205mm x 360mm [Width x Depth].
Size [cm]: 120.5cm x 36cm [Width x Depth].
Double Bowl Basin.
40mm (4cm) Profile basin.
Rear tap basin with one tap hole.
Overflow and cover included.
Details For Ceramic Basin:.
It comes in a white finish.
Manufactured using Vitreous china material.
Size [mm]: 1205mm x 360mm [Width x Depth].
Size [cm]: 120.5cm x 36cm [Width x Depth].
Double Bowl Basin.
50mm (5cm) Profile basin.
Rear tap basin with one tap hole.
Overflow and cover included.
The tap Shown in the image is not included.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Sink Height
: 103
⤷ Sink Width
: 1205
⤷ Sink Projection
: 360
⤷ Range
: Fusion
⤷ Handle Finish
: Satin Nickel
⤷ Colour
: Gloss Grey
⤷ Weight in kg
: 59.12
⤷ Warranty/Guarantee
: 5 Year
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Width
: 1200
⤷ Depth
: 353
⤷ Height
: 864
⤷ Fixings included
: Yes
⤷ No. of Tap Holes
: 1 On Each Bowl

⤷ Overflow Included
: Yes
⤷ Compliance/Approvals/Standard
: FSC Certified
⤷ Barcode
: 5056211816744
⤷ Number Of Doors
: 4
⤷ Handle Included
: Yes
⤷ Product Type
: Vanity Unit
⤷ Furniture Material
: MDF And MFC
⤷ Sink Included
: Yes
⤷ Sink Colour
: White
⤷ No. Of Internal Shelves
: 1
⤷ Soft-Close Door
: Yes
⤷ Sink Material
: Polymarble
⤷ Number Of Sinks
: 2
⤷ Sink Shape
: Rectangular
⤷ Sink Type
: Inset

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instruction Pdf File

Technical Images

Hudson Reed Fusion 1200mm Full Depth Floor-Standing Vanity Unit And Basin

Total: £431.20 3-4 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Soft-Close Opening

This product has a mechanism for doors and drawers to open or close slowly, silently and without loud slamming.

Rigid Furniture - Pre-Assembled

Rigid or pre-assembled furniture is any bathroom unit that is ready to install. These arrive entirely constructed with pre-drilled holes and labelled parts making the furniture installation process quick and easy. It helps you save money on labour, and you get a higher-quality product. These are also an excellent choice for anyone looking for a new storage unit that fits their bathroom decor.

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

Cam & Dowel Method

It is a woodworking process in which a dowel or wooden pin is fit into a pre-carved hole in the opposite pieces of wood to create a strong joint. The resulting piece of furniture has a rigid carcass with a neat finish and removes the need for glue or nails for adhesion.

FSC Certified

Any product with this logo is made of wood from well-managed, sustainable forests. Its full form is certified by the Forest Stewardship Council. By buying such products, you are supporting responsible forestry.
