Reina Matera 500mm Wide Steel Designer Radiator

Reina Matera RND-MTR5077A Details

Reina Matera 500mm Wide Steel Designer Radiator.

Key Features

✔Supplied with Air vent and End plug
✔Manufactured using mild steel material
✔Choice of different finish: Anthracite and Chrome
✔Five-year guarantee from Reina against manufacturing defects

Available in different heights: 772mm, 998mm and 1412mm - [Optional].
Available variants: Central heating, Dual Fuel, and Electric - [Optional].
Choice of heating element available - [Optional].
Width: 500mm (50cm).
Pipe centers: 100mm (10cm).
Wall to pipe centres: 61mm-76mm (6.1cm-7.6cm).
Distance from wall: 110mm-125mm (11cm-12.5cm).
EN 442 Compliant product.
Suitable for central, electric, and dual fuel heating systems.

Brackets for radiator included.
Valves, Chrome pipe kit [Optional].
For the Dual Fuel and Electric model, Heating Elements are highly recommended in combination with T-Piece.
For Electric models, Optional Liquid Filling is required with the heating element.
The image shown is for illustration purposes only.
Download the Installation and Heating Element Manual Instruction PDF File from the Additional Info Section.
Refer to the technical diagram for complete technical dimensions.
The valves shown in the image are not included.

Please Note: The appropriate wattage of the element if selected will be decided by the manufacturer, once the order is placed.

Radiator Calculator

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Matere
⤷ Colour
: Anthracite
⤷ Shape
: Straight
⤷ Country of Origin
: Turkey
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Mild Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Width
: 500
⤷ Height
: 772
⤷ Orientation
: Vertical

⤷ Compliance/Approvals/Standard
: EN 442
⤷ Barcode
: 5057199875556
⤷ BTU Output
: 70°C - 1784
⤷ Watts
: 70°C - 523
⤷ Tapping / Pipe Centres
: 100
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating | Electric | Dual Fuel
⤷ Wall to Centre of Inlet
: 61-76
⤷ Heating Element Included
: Sold Separately
⤷ Element Type
: Standard | Thermostatic | Digital
⤷ Brackets Included
: Yes

Additional Info & Downloads

Download the Installation Instruction Pdf File Download the Heating Element Manual Instructions Pdf File Download the Details Of Heating Elements Pdf File

Technical Images

Reina Matera 500mm Wide Steel Designer Radiator

Customise Your Product

Optional Accessories

Reina provides optional accessories that you may require for the installation. The manufacturer highly recommends these Accessories. Please Note: The image shown is for illustration purpose only.

No Option Selected
OP-113634 - 200mm Chrome Pipe Kit + £14.14

Total: £133.55 5 Working Days Approx QS Supplies

Product Variations Info & MFC Code

Height	722mm	998mm	1412mm
Finish	Anthracite	Anthracite	Anthracite
Pipe Centres	100	100	100
Wall to Pipe centres	61-76	61-76	61-76
Wall Distance	110-125	110-125	110-125
Tube Quantity	6	8	11
Total Gap	5	7	10
Fuel Type	Central/Electric/Duel	Central/Electric/Duel	Central/Electric/Duel
Watts - Delta-70	523	706	980
BTU - Delta-70	1784	2408	3341
BTU - Delta-60	1462	1974	2739
BTU - Delta-50	1151	1554	2155
BTU - Delta-45	1002	1353	1877
BTU - Delta-40	866	1169	1622
BTU - Delta-35	725	979	1358
BTU - Delta-30	589	795	1103
BTU - Delta-25	229	310	429
MFC	RND-MTR5077A	RND-MTR5099A	RND-MTR5141A

Height	722mm	998mm	1412mm
Finish	Chrome	Chrome	Chrome
Pipe Centres	100	100	100
Wall to Pipe centres	61-76	61-76	61-76
Wall Distance	110-125	110-125	110-125
Tube Quantity	6	8	11
Total Gap	5	7	10
Fuel Type	Central/Electric/Duel	Central/Electric/Duel	Central/Electric/Duel
Watts - Delta-70	366	494	685
BTU - Delta-70	1248	1684	2337
BTU - Delta-60	1023	1380	1916
BTU - Delta-50	805	1086	1508
BTU - Delta-45	701	946	1313
BTU - Delta-40	606	817	1134
BTU - Delta-35	507	685	950
BTU - Delta-30	412	556	771
BTU - Delta-25	160	216	300
MFC	RND-MTR5077	RND-MTR5099	RND-MTR5141

5 Features Included In This Product Explained

Central Heating

'Standard' radiators and towel warmers are connected to your central heating system, so hot water flows through them to heat them.
Read more...

Optional: Dual Fuel

These radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These radiators are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).

Mild Steel

Mild Steel is the most common radiator material. It is inexpensive, available in a variety of designs and finishes, lightweight and durable.

Optional: Radiator Valve

Radiator valves help control how much hot water enters and leave it, and the flow of water controls how much heat the radiator generates. These are usually found at the radiator's bottom left, and right corners, where the water pipes enter and exit, or can also be present at the bottom near the centre.
Read more...

Optional Sleeving Kit

A sleeving kit in a radiator heating system are components or materials used to sleeve or insulate the pipes or tubes that circulate hot water or steam from the central heating source to the radiators or heating units. The sleeving kit provides thermal insulation and prevents heat loss, adding to the heating systems efficiency.
