Hudson Reed Fusion 360mm Full Depth Floor-Standing Vanity Unit And Basin

Hudson Reed Fusion CBI124 Details

Hudson Reed Fusion Full Depth Vanity Unit And Basin is designed to last through years of use with no signs of wear. Supplied with sufficient storage to keep clutter out of sight, this model is available for purchase in three possible width options and numerous finishes. The product is suitable for Floor-Standing installation within any modern or traditional bathroom layout, anywhere. It is realised from MFC painted gloss and supplied rigid and ready to use. A white finished polymarble basin comes included with the vanity. This unit looks best when paired with a LED mirror.

Key Features

✔2 Soft close doors with one internal shelf
✔Fascia Material Finish: MDF Painted Gloss
✔Cabinet Material Finish: MFC Painted Gloss
✔Construction method: Cam and Wood Dowel
✔Five-year guarantee from Hudson Reed against manufacturing defects

Available in 500mm, 600mm and 800mm sizes - [Optional].
Choice of finishes available: Gloss White, Anthracite Woodgrain, Charcoal Black, Gloss Grey and Bleached Oak - [Optional].
Available in Polymarble and Ceramic Basin Type - [Optional].
Overall Size [mm]: 360mm x 904mm [Depth x Height].
Overall Size [cm]: 36cm x 90.4cm [Depth x Height].
Made in Britain to the highest quality standard.
Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section.
Refer to the Technical drawing for More technical specifications.
Details For Vanity Unit:.
Size [mm]: 500mm x 353mm x 864mm [Width x Depth x Height].
Size [cm]: 500cm x 35.3cm x 86.4cm [Width x Depth x Height].
Hinge type: 95 Degree Clip-On Soft Close.
Cabinet Thickness: 16mm (1.6cm).
Fascia thickness: 18mm (1.8cm).
FSC Certified.
Fixing included.
Supplied Rigid.
Contemporary Wrap over handle in Satin nickel finish included.
Full-depth offers ample storage capacity.
Choice of other handles in different finishes available [Optional].

Details For Polymarble Basin:.
It comes in a white finish.
Manufactured using poly marble material.
Size [mm]: 503mm x 355mm [Width x Depth].
Size [cm]: 50.3cm x 35.5cm [Width x Depth].
Inner bowl depth: 103mm (10.3cm).
40mm (4cm) Profile basin.
CE and UKCA approved.
Rear tap basin with one tap hole.
Overflow and cover included.
Details For Ceramic Basin:.
It comes in a white finish.
Manufactured using Vitreous china material.
Depth: 360mm (36cm).
Inner bowl depth: 103mm (10.3cm).
50mm (5cm) Profile basin.
CE and UKCA approved.
Rear tap basin with one tap hole.
Overflow and cover included.
The tap shown in the image is not included.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Sink Height
: 135
⤷ Sink Projection
: 207.5
⤷ Sink Width
: 503
⤷ Range
: Fusion
⤷ Finish Front
: Gloss
⤷ Handle Finish
: Satin Nickel
⤷ Colour
: Gloss White
⤷ Weight in kg
: 26.1
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Waste Included
: Sold Separately
⤷ Width
: 500
⤷ Depth
: 355
⤷ Height
: 864
⤷ Fixings included
: Yes
⤷ No. of Tap Holes
: 1

⤷ Overflow Included
: Yes
⤷ Compliance/Approvals/Standard
: FSC Certification
⤷ Barcode
: 5055275887264
⤷ Number Of Doors
: 2
⤷ Handle Included
: Yes
⤷ Product Type
: Vanity Unit
⤷ Furniture Material
: MFC Gloss
⤷ Pre-assembled
: Yes
⤷ Sink Included
: Yes
⤷ Sink Colour
: White
⤷ No. Of Internal Shelves
: 1
⤷ Soft-Close Door
: Yes
⤷ Door Opening
: Left Right
⤷ Sink Material
: Polymarble
⤷ Number Of Sinks
: 1
⤷ Sink Shape
: Rectangular
⤷ Sink Type
: Inset

Additional Info & Downloads

Download the Customer Data Sheet For 500mm Unit And Basin Pdf File Download the Customer Data Sheet For 600mm Unit And Basin Pdf File Download the Customer Data Sheet For 800mm Unit And Basin Pdf File Download the Installation Instruction Pdf File

Technical Images

Hudson Reed Fusion Full Depth Floor-Standing Vanity Unit And Basin

Total: £197.05 3-4 Working Days Approx QS Supplies

7 Features Included In This Product Explained

Soft-Close Opening

This product has a mechanism for doors and drawers to open or close slowly, silently and without loud slamming.

Rigid Furniture - Pre-Assembled

Rigid or pre-assembled furniture is any bathroom unit that is ready to install. These arrive entirely constructed with pre-drilled holes and labelled parts making the furniture installation process quick and easy. It helps you save money on labour, and you get a higher-quality product. These are also an excellent choice for anyone looking for a new storage unit that fits their bathroom decor.

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

Cam & Dowel Method

It is a woodworking process in which a dowel or wooden pin is fit into a pre-carved hole in the opposite pieces of wood to create a strong joint. The resulting piece of furniture has a rigid carcass with a neat finish and removes the need for glue or nails for adhesion.

Vitreous-China Material

It is a compound of glass and silica-based materials applied as a coat on porcelain products such as WC pans, urinals, baths and basins to protect them from scratches and stains as an anti-vandal measure.

Melamine Faced Chipboard

Melamine Faced Chipboard or MFC is a type of engineered wood with a smooth surface. It is made using wood chips, then formed into particle board using heat and pressure and bonded to melamine resin impregnated paper. The Melamine layer makes it waterproof, and helps resist scratches, and increases the aesthetics. It is cheaper than MDF or Medium Density Fiberboard.

FSC Certified

Any product with this logo is made of wood from well-managed, sustainable forests. Its full form is certified by the Forest Stewardship Council. By buying such products, you are supporting responsible forestry.
