Nuie Colosseum Triple Column White Vertical Radiator

£121.80

STOCK AVAILABILITY

3-4 Working Days Approx

4.5 out of 5 4.5 out of 5

Based on 2 Ratings.

Shipping: £20.00

Product Variants
Select Width Step 1
Select Height Step 2
SKU Code: QS-V0812

MFC Code: HX308

Nuie Colosseum HX308 Details

The Triple Column Radiator manufactured by Nuie is meticulously crafted, with a compact, tubular design welded together to give it a unique look enhanced further by the superb glossy white finish. Suitable for wall-mount installation, this high-quality vertical radiator is finished in white, which adds the finishing touch to your lavish home decor. Slim and smart, the radiator gives a sophisticated appeal to your home and emits immense heat output to keep your home pleasingly warm.

This is the one for sure if you are looking for a radiator for an ample space or a high-ceilinged room. Because it has a larger surface area, it gives off more heat, and its vertical profile can help. This functional heating machine is supplied with a complete fixing screw for easy installation, and it carries a 5-year guarantee against any manufacturing defects from the manufacturer. You can purchase Radiator valves and other accessories separately.

Key Features
  • It comes in a white finish
  • Supplied complete with fixing screws
  • Five-year guarantee from Nuie against manufacturing defects
  • Available in different widths: 287mm, 368mm and 376mm - [Optional].
  • Choice of different heights: 1500mm and 1800mm - [Optional].
  • It comes in a white finish.
  • Tube Diameter: Ø25mm (2.5cm).
  • Max projection: 180mm (18cm).
  • Wall to Centre of Tapping: 75mm (7.5cm).
  • All tapping are 1/2 inch BSP.
  • Vertical design.
  • Excellent heat output at Delta t60°c.
  • Supplied complete with fixing screws.
  • Recommended use of suitable inhibitor at the time of refilling the new radiator after installation.
  • Dimensions shown are subject to minor deviations.
  • Floor Mounted Legs Set - [Option].
  • Suitable valve available in Compatible Valves tab below - [Optional].
  • Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section.
  • For complete size details, please refer to the technical drawing.
  • Five years guarantee from Nuie against manufacturing defects.
  • Details For 287mm x 1500mm:.
  • Size: Width 287mm (28.7cm) x Height 1500mm (150cm).
  • BTU: 30°C - 1468, 50°C - 2897, 60°C - 3670.
  • Watts: 30°C - 430, 50°C - 849, 60°C - 1060.
  • Pipe centre: 381mm (38.1cm).
  • Details For 287mm x 1800mm :.
  • Size: Width 291mm (29.1cm) x Height 1800mm (180cm).
  • BTU: 30°C - 1717, 50°C - 3348, 60°C - 4241.
  • Watts: 30°C - 503, 50°C - 981, 60°C - 1249.
  • Pipe centre: 381mm (38.1cm).
  • Details For 368mm x 1500mm:.
  • Size: Width 368mm (36.8cm) x Height 1500mm (150cm).
  • BTU: 30°C - 1959, 50°C - 3863, 60°C - 4894.
  • Watts: 30°C - 574, 50°C - 1132, 60°C - 1443.
  • Pipe centre: 471mm (47.1cm).
  • Details For 376mm x 1800mm:.
  • Size : Width 376mm (37.6cm) x Height 1800mm (180cm).
  • BTU: 30°C - 2290, 50°C - 4463, 60°C - 5654.
  • Watts: 30°C - 671, 50°C - 1308, 60°C - 1659.
  • Pipe centre: 471mm (47.1cm).

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Colosseum
  • ⤷ Colour
  • : White
  • ⤷ Shape
  • : Curved
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Material
  • : Steel
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Projection (Depth)
  • : 180
  • ⤷ Width
  • : 287
  • ⤷ Height
  • : 1500
  • ⤷ Fixings included
  • : Yes
  • ⤷ Orientation
  • : Vertical
  • ⤷ Barcode
  • : 5055146171737
  • ⤷ BTU Output
  • : 30°C - 1468 | 50°C 2897 | 60°C - 3670
  • ⤷ Watts
  • : 30°C - 430 | 50°C - 849| 60°C - 1060
  • ⤷ Tapping / Pipe Centres
  • : 381
  • ⤷ Valves Included
  • : Sold Separately
  • ⤷ Wall to Centre of Inlet
  • : 75
  • ⤷ Tube Diameter
  • : 25
  • ⤷ Brackets Included
  • : Yes
  • ⤷ No. of Columns
  • : 3

Additional Info & Downloads

Download PDF Download the Customer Data Sheet For 287 x 1500mm Pdf File Download PDF Download the Customer Data Sheet For 287 x 1800mm Pdf File Download PDF Download the Customer Data Sheet For 368 x 1500mm Pdf File Download PDF Download the Customer Data Sheet For 376 x 1800mm Pdf File Download PDF Download the Installation Instruction Pdf File


Technical Images


Customise Your Product

Floor Mounting Legs
Floor Mounting Legs

Hudson Reed floor mounting radiator legs suitable for floor installation of the radiator where wall mounting is not possible. Please note: The image is for illustration purposes only.
