Twyford Aspect White Designer Acrylic Single Ended 1700mm Bath


RRP: £314.70


6 Working Days Approx.

4.0 out of 5 4.0 out of 5

Based on 4 Ratings.

Shipping: £34.95

Select Variations
You've Selected: OP-155677 - No Tap Hole - 1700 x 700mm
Key Features
  • Compatible for use with folding or fixed bath screens
  • Manufactured using 4mm thick acrylic sheet reinforced with glass fibre
  • Encapsulated baseboard for extra protection in damp or humid conditions
  • Bath manufactured to European and British standards EN263/EN14516 CL1
  • 25 years of guarantee from the manufacturer against any manufacturing defects
SKU Code: QS-V10729

MFC Code: AP8500WH

Twyford Aspect AP8500WH Details

Revitalise yourself in an elegant style, with the Twyford Aspect Acrylic Bath, which has a unique rectangular form. This bathtub comes in a glossy white finish, to match other bathroom accessories, seamlessly. Its 4mm thick acrylic construction, reinforced with glass fibre makes this bathtub extremely durable. It has a spacious, profile, supported on wooden frame with steel cradle and feet, to provide utmost comfort. Its encapsulated baseboard offers resistance against dampness and humidity and has stable non-fading colour. The manufacturer backs this bath with a 25-year guarantee, against any manufacturing defects.

  • Available in 3 variations - 2 tap holes with 1700 x 700mm, no tap holes with 1700 x 700mm, no tap holes with 1700 x 750mm.
  • Comes in white finish.
  • Contemporary square design.
  • Supported on a wooden frame with a steel cradle and adjustable feet.
  • Clips were provided for securing to wall.
  • Waste shown in the image is not included - sold separately.
  • Size in [mm]: 1700mm x 704mm x 385mm [Length x Width x Depth].
  • Size in [cm]: 170cm x 70.4cm x 38.5cm [Length x Width x Depth].
  • Overall Height: 545mm [54.5cm].
  • Water Capacity - 190 litres up to the overflow.
  • Suitable for residential, commercial, hotel and leisure applications.
  • Download the Installation Instruction PDF File from the Additional Info Section.
  • For complete size details, please refer to the technical drawing.
  • Specification For 1700 x 700mm Bath:.
  • Size: 1700mm [170cm] x 704mm [70.4cm] x 510mm [51cm] [Length x Width x Height].
  • Water capacity: 190 litres [up to the overflow].
  • Specification For 1700 x 750mm Bath:.
  • Size: 1700mm [170cm] x 755mm [75.5cm] x 510mm [51cm] [Length x Width x Height].
  • Water capacity: 220 litres [up to the overflow].
  • Optional Products:.
  • Endurance Front.
  • End Panel.

Info / Size (mm)

  • Bath
  • Length: 1700 mm
  • Width: 704 mm
  • Depth: 385 mm

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Aspect
  • ⤷ Position of Drain
  • : Foot-End
  • ⤷ Interior Shape
  • : Rectangular
  • ⤷ Bath Type
  • : Standard
  • ⤷ External Length
  • : 1700
  • ⤷ External Width
  • : 700
  • ⤷ Tub Depth
  • : 385
  • ⤷ Feets Included
  • : Yes
  • ⤷ Height Including Feet or Panel
  • : 510
  • ⤷ Front Panel Included
  • : Sold Separately
  • ⤷ End Panel Included
  • : Sold Separately
  • ⤷ Colour
  • : White
  • ⤷ Internal Top Length
  • : 1520
  • ⤷ Internal Top Width
  • : 540
  • ⤷ Height of Rim
  • : 35
  • ⤷ Distance Tub edge to centre of drain hole
  • : 235
  • ⤷ Distance Top edge to centre of overflow hole
  • : 70
  • ⤷ Distance foot end of tub edge to center of foot
  • : 340
  • ⤷ Weight in kg
  • : 19.37
  • ⤷ Shape
  • : Rectangular
  • ⤷ Capacity in litres
  • : 190
  • ⤷ Country of Origin
  • : UK
  • ⤷ Warranty/Guarantee
  • : 25 Years
  • ⤷ Material
  • : Acrylic
  • ⤷ No. of Bathers
  • : 1
  • ⤷ Theme
  • : Modern
  • ⤷ Waste Included
  • : Sold Separately
  • ⤷ Tap Holes
  • : Un-drilled
  • ⤷ Barcode
  • : 5024959394398

Additional Info & Downloads

Customise Your Product

Front And End Panels
Front And End Panels

Modern front and end bath panels. Please Note: The image shown is for illustration purpose only.

Pop-Up Waste
Pop-Up Waste

Exclusive bath pop-up waste and overflow to suit your bathtub. Please note: The image is for illustration purposes only.

Total: £186.59 6 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Encapsulated Base Board

Encapsulated Base Board

The encapsulated base board has been coated with Glass Reinforced Plastic (GRP) to strengthen it and add a sealing quality to the construction while protecting it from water damage. It goes around the tub and the drain hole, supports the tub, and assists in sealing the underside from moisture.

With / Without Overflow

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called “without overflow” and will need a compatible drain.

Optional: Front Panel

Optional: Front Panel

A front bath panel is a decorative accessory that is used to cover the front-facing side of a bathtub for a neat and polished look. It also conceals plumbing and framework and comes in different sizes, textures and materials.

Optional End Panel

Optional End Panel

End Panels serve an aesthetic purpose to cap-off the exposed end of a bathtub and come in different sizes, shapes, designs, and finishes.
