Ideal Standard Tesi White Wall Hung WC Pan with Aquablade Technology

Not Yet Rated No Rating

£335.29

RRP: £419.11
SKU: QS-V113134
Key Features
  • Manufacturing Using Vitreous China Material
  • Standards: WC Bowl to BS EN 997 & BS EN 33
  • Lifetime Guarantee from the Manufacturer Against any Manufacturing Defects
  • Features a Water-Efficient Design with New AquaBlade® Flushing Technology and a completely Hidden Fixation System
Pay in 3-Interest Free Payments
Shipping

Shipping: £39.99

Stock Availability

Stock Availability:

5 Working Days Approx.

Ideal Standard Tesi Details

MFC: T007901

Ideal Standard Tesi White Wall Hung WC Pan with Aquablade Technology.

  • It Comes in a White Finish
  • Horizontal Outlet
  • Size [mm]: 360 x 400mm [Width x Height]
  • Size [cm]: 36 x 40cm [Width x Height]
  • Projection from the Wall: 530mm [53cm]
  • Domestic and Commercial Use
  • Weight: 22kg
  • Concealed Cisterns, Flush Plate and Button and Support Frame [Optional]
  • Fix the E0060 Support Brackets to the Floor Within the duct and Secure the WC with bolts [Supplied]
  • A Hidden Fixing Set is Provided, Screw the bolts to the Back Wall
  • The WC Bowl Should not be Installed with Lever-Activated Cisterns Fitted with a Syphon
  • Watch or Download a Video from the Additional Info Section showing how AquaBlade Technology Works
  • Download the Installation Instruction PDF File from the Additional Info Section
  • Refer to the Technical Drawing for More Technical Details
  • The Seat and Cover Shown in the Image are Not Included
  • AQUABLADE® Flush Technology Features:
  • With Simple, Clean Lines and Contemporary Styling, the Unpleasant, Overhanging Rim is not Visible -- Only Smooth Curves are Visible
  • 80% of Consumers Prefer this Technology Over Standard Box Rim and Rimless Toilet
  • It Offers Superior Flush Performance Every Time
  • Its Unique Design helps Water Flow from the Top of the Bowl, Enabling 90% of the Area to be Rinsed Clean
  • The Internal Channel generates a Pressurised Cascade of Water That Flows Around the Bowl
  • Two Strong Jets Merge, and as a Result, a Powerful Plume is Formed That Drives Solid matter Easily
  • Overtakes All Existing WCs When it Comes to Hygiene
  • A significant Area of Traditional Bowls is Left unwashed, Particularly the Back Bowl
  • Ensures 100% of the Surface Area Below the Channel is Rinsed Clean
  • Bacteria Can Harbour Around the Shelf Area in Rimless Toilets, and Water Can Splash Over the Edge of the Bowl, releasing Bacteria Particles Into the Air and Ensuring That the Bacteria are Completely Washed Away with No Splashing Even

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Tesi
  • ⤷ Colour
  • : White
  • ⤷ Weight in kg
  • : 22
  • ⤷ Warranty/Guarantee
  • : Lifetime
  • ⤷ Material
  • : Vitreous China
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Water Saving
  • : Yes
  • ⤷ Projection (Depth)
  • : 530
  • ⤷ Cistern Included
  • : Sold Separately
  • ⤷ Width
  • : 360
  • ⤷ Outlet
  • : Horizontal
  • ⤷ Configuration
  • : WC Pan Only
  • ⤷ Height
  • : 400
  • ⤷ Seat Included
  • : Sold Separately
  • ⤷ Fixings included
  • : Yes
  • ⤷ Fixing Holes Centre
  • : 180
  • ⤷ Compliance/Approvals/Standard
  • : BS EN 997 | BS EN 33
  • ⤷ Barcode
  • : 8014140435235
  • ⤷ Distance from floor to centre of fixing hole
  • : 320
  • ⤷ Bowl Shape
  • : Round
  • ⤷ Product Type
  • : Wall Hung WC
  • ⤷ Seat Post Hole Centers
  • : 155
  • ⤷ Front Of Bowl To Centre Of Seat Holes
  • : 430
  • ⤷ Outlet Diameter
  • : 102
  • ⤷ Base to centre of outlet
  • : 220

Additional Info & Downloads

Download PDFDownload the Installation Instruction Pdf File

Add-Ons

WC Frame
WC Frame

Frame for WC and bidet. Please Note: The image shown is for illustration purpose only.

Flush Plate
Flush Plate

Flush Plate Please note: the image shown is for illustration purpose only.

Wall channel - for uneven surfaces such as mosaic
Wall channel - for uneven surfaces such as mosaic

Optional accessories available. Please note image is for illustration purpose only

Support
Support

Support frame and bolts for wall-hung WC pan! Please note: The image shown is for illustration purpose only.

Videos

Video of Ideal Standard AquaBlade Flushing Technology

£335.29
RRP: £419.11
Stock Availablity: 5 Working Days Approx
QS Supplies

5 Features Included In This Product Explained

AQUABLADE FLUSH TECHNOLOGY

AQUABLADE FLUSH TECHNOLOGY

AquaBlade is an award-winning, patented flush technology. It offers a superior flushing action, even with low water volume. The AquaBlade system is an intelligent innovation in flushing that gives a cleaner, quieter flush, thanks to a more innovative design, to offer unmatched hygiene. Upon flushing, the system creates a wall of water that cascades from the top of the toilet bowl, along with two powerful plumes of water, for energising flushing action. The toilet is designed so that it flush bacteria away with a powerful flushing system without splashing.

Horizontal Outlet

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.

Vitreous-China Material

Vitreous-China Material

Vitreous china is an innovative glass-based enamel coating applied to porcelain. This glazed coating makes the base material durable, denser, and very glossy. When ceramics are coated with vitreous enamel, the resulting product is called vitreous china. This enamel is created by applying heat to powdered glass.

BS EN 997 Standard

BS EN 997 Standard

This standard specifies the constructional, performance requirements and test methods for close-coupled suites, one-piece and independent WC pans with integral traps used for personal hygiene made using vitreous china or stainless steel. Compliance with this standard aims to ensure reliability, performance and safety.

BS EN 33 Standard

BS EN 33 Standard

BS EN 33 specifies requirements for the connecting dimensions of WC pans and related cisterns, irrespective of the materials they are made of. The focus of this standard is to ensure that the products are compatible and their assembly is correct, so they can be interchanged when needed and parts can also be replaced when needed.
