Joseph Miles 1700mm Curved-P Whirlpool Bath With Front Panel And Screen

£955.00

STOCK AVAILABILITY

5-7 Working Days Approx

4.3 out of 5 4.3 out of 5

Based on 3 Ratings.

Shipping: FREE* Check Postcodes

Product Variants
Select Bath Step 1
Select Variant Step 2
Select Whirlpool Water Heater Step 3
Select Earth Leakage Circuit Breaker Step 4
Select Colour Dynamic Underwater Light Step 5
Select End Panel Step 6
SKU Code: QS-V94251

MFC Code: JM-XXQS25S1

Joseph Miles Curved-P JM-XXQS25S1 Details

The best part of Joseph Miles baths is the availability of options and features, allowing you to choose precisely what is suitable for your home and personal needs. Pictured here is the 1700mm Curved-P Whirlpool Bath with Front Panel and Screen- a bathtub that incorporates Whirlpool, Airpool or both Systems for purchase as needed.

Ideal for any contemporary living area, it is designed and constructed in P-shape and stunning white finish for visual splendour and the ultimate strength and rigidity. Its generous interior allows for a comfortable soak, and variants are available in the right or left hand. The bath has multiple jets placed at strategic points across the interior for a complete spa-like experience within the home. The front panel and bath screen come included with this product.

Key Features
  • Includes bath, front panel and bath screen
  • It comes un-drilled, giving you an option of different tap combinations
  • Ultimate in strength and rigidity
  • Whirlpool On/Off Switch
  • Twenty years guarantee on bath against manufacturing defects.
  • Available in different variants: Whirlpool, Airpool and Whirlpool-Airpool [Optional].
  • Bath variant: Left hand and Right hand [Optional].
  • Size: Length 1690mm x Height: 420mm x Width 700-850mm.
  • It comes in a white finish.
  • Curved P-shaped bath.
  • Bath and shower screen height 2045mm.
  • Water capacity (litres): 210L.
  • Bath waste and overflow cover shown in the image are not included.
  • Download Installation Instruction PDF File from the Additional Info Section.
  • Refer technical drawing for more details.
  • Whirlpool System: 12 Jets.
  • 2 x Air Flow Controls.
  • Directional Whirlpool Jets.
  • Back Foot Jets.
  • Safety Suction Filter.
  • Dry-Run Pump Protection.
  • Airpool System: 12 Jets.
  • Airpool On/Off Switch.
  • Airpool Jets.
  • Dual System: Whirlpool-Airpool 24 Jets.
  • Whirlpool On/Off Switch.
  • Airpool On/Off Switch.
  • 2 x Air Flow Controls (Whirlpool).
  • Directional Whirlpool Jets.
  • Back Foot Jets.
  • Airpool Jets.
  • Safety Suction Filter.
  • Dry-Run Pump Protection (Whirlpool).
  • Optional Accessories For Bath:.
  • Bath end panel.
  • ELCB Protection - for all system.
  • Colour dynamic underwater light - for all system.
  • Inline Heater - for Whirlpool and dual system.

Note: The Airpool system will start a self-clean cycle approximately 15 minutes after use. The length of clean will vary, do not interrupt this cycle.


Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Position of Drain
  • : Foot-End
  • ⤷ Interior Shape
  • : P-Shaped
  • ⤷ Bath Type
  • : Whirlpool Bath
  • ⤷ Coating
  • : Without Coating
  • ⤷ External Length
  • : 1690
  • ⤷ External Width
  • : 700-850
  • ⤷ Front Panel Included
  • : Yes
  • ⤷ End Panel Included
  • : Sold Separately
  • ⤷ Colour
  • : White
  • ⤷ Internal Bottom Length
  • : 1200
  • ⤷ Internal Bottom Width
  • : 360-560
  • ⤷ Internal Top Length
  • : 1590
  • ⤷ Internal Top Width
  • : 561-769
  • ⤷ Height of Rim
  • : 40
  • ⤷ Distance Top edge to centre of overflow hole
  • : 75
  • ⤷ Diameter of overflow hole
  • : 52
  • ⤷ Diameter of Drain hole
  • : 52
  • ⤷ Rim Width
  • : 50.5, 60, 61, 70
  • ⤷ Shape
  • : P-Shaped
  • ⤷ Capacity in litres
  • : 210
  • ⤷ Handed Type
  • : Left Hand
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Material
  • : Glass and Material
  • ⤷ No. of Bathers
  • : 1
  • ⤷ Theme
  • : Modern
  • ⤷ Bath Therapy Type
  • : Airpool & Wirlpool
  • ⤷ Number of Jets
  • : 12
  • ⤷ Waste Included
  • : Sold Separately
  • ⤷ Barcode
  • : 5057199957993

Additional Info & Downloads

Download PDF Download the Installation Instructions Pdf File


Technical Images
