Vogue Studio 500mm Wide Chrome Straight Towel Rail

Vogue Studio MD006 BR0720500CP Details

Extend your relaxation to your bathroom by making use of warm towels by installing the Vogue Studio 500mm Straight Towel Rail. The towel rail is specifically made with top quality brass that will easily withstand the humidity of the bathroom. The unit features a straight horizontal design that has been given a glossy chrome finish that will make an attractive presentation within any interior. The profile makes it suitable for mounting in modern bathrooms while the chrome hue allows it to work in any bathroom style regardless of the decor easily.

Key Features

✔Manufactured using brass material
✔Corrosion-resistant
✔High heat output
✔Thirty-year guarantee from Vogue against manufacturing defects

Available in different sizes: 720mm, 1000mm and 1435mm [Optional].
Available variations - Heating Only, Heating and Electric and Electric only Version [Optional].
Images are for illustration purposes only.
The valves shown in the image are not included.
Size [mm]: 500mm x 82-102mm [Width x Depth}.
Size [cm]: 50cm x 8.2-10.2cm [Width x Depth}.
Pipe centre: 468mm (46.8cm).
Superior finish.
Suitable for all systems.
Refer to the technical diagram for the complete technical dimension.
Download the Ral colour chart PDF File from the Additional Info Section.
Available Options.
Arne valve.
Heating elements.
Connection tube.
Round internal diameter hinged cover plates.
Flexi cover shroud (suitable for use with standard element only).
Specification For 720mm Towel Rail.

Bar Configuration: 4-4-6.
Output @50°C Watts: 327W.
Output @50°C BTU: 1116.
Output @60°C BTU: 1415.
Heating Element required: 125W.
Specification For 1000mm Towel Rail.
Bar Configuration: 6-7-8.
Output @50°C Watts: 482W.
Output @50°C BTU: 1645.
Output @60°C BTU: 2086.
Heating Element required: 200W.
Specification For 1440mm Towel Rail.
Bar Configuration: 6-8-8-8.
Output @50°C Watts: 690W.
Output @50°C BTU: 2354.
Output @60°C BTU: 2985.
Heating Element required: 300W.

Please Note: Select RAL Colours as per your preference from the PDF provided in the additional info section and email us the colour, or you can simply contact our Live Chat Support or call 0116 251 0051 and mention the colour you like from RAL Colour Chart.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Studio
⤷ Colour
: Chrome
⤷ Shape
: Straight
⤷ Country of Origin
: UK
⤷ Warranty/Guarantee
: 30 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Projection (Depth)
: 82-102

⤷ Width
: 500
⤷ Barcode
: 5051278109976
⤷ BTU Output
: 50°C - 1116 | 60°C - 1415
⤷ Watts
: 327
⤷ Tapping / Pipe Centres
: 468
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Heating | Heating & Electric | Electric
⤷ Heating Element Included
: Sold Separately
⤷ Element Type
: Standard | Thermostatic

Additional Info & Downloads

Download the PDF For RAL Colour Chart Pdf File

Technical Images

Vogue Studio 500mm Wide Chrome Straight Towel Rail

Customise Your Product

Optional Accessories

Optional accessories are available for this product. Please note image is for illustration purpose only

OP-146250 - 15mm x 150mm Long Tubes + £35.06
OP-146251 - 22mm x 150mm Long Tubes + £44.41
OP-146253 - Round 15mm Cover Plate + £24.16
OP-146252 - Flexi cover shroud + £112.97

Total: £687.10 10-14 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Heating And Hot Water

Central heating radiators and towel warmers are connected to your central heating system, so hot water flows through them to heat them up. Standard radiators and towel warmers are those which connect to central heating systems.

Heating And Electric

Dual Fuel radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These products are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).

Electric Only

Electric Only options are independent units requiring a fused spur electric connection. Electric Only radiators and towel warmers are powered by the mains electrical supply instead of a gas boiler. You can turn on each radiator or towel warmer as and when you need them.

DZR Brass

High quality brass plated finish that resists corrosion.

RAL Colours

It refers to a European colour-matching system which defines colours for coatings, paints, and plastics. The colour standard is administrated by the RAL Deutsches Institut für Gütesicherung und Kennzeichnung.
