Vado Life Slimline Chrome Mono Basin Mixer Tap

Vado Life LIF-200/SB-CP Details

The Vado Life Slimline Mono Basin Mixer Tap is a smooth-bodied, single-lever operated unit that is especially suitable for installing modern bathroom style. This unit is designed for deck-mounted installation; this unit comes with a directional water flow aerator and 2 1/2 inch 400 mm flex pipe connections. Requiring a minimum operating pressure of a 1.0 bar for proper functionality, this product is ideal for installing a high water pressure system. It can include click-clack waste along with it if desired. Looks best with a countertop, wall-hung or a cloakroom basin.

Available With or Without waste.
Deck mounted installation.
Smooth bodied.
Size [mm]: 50mm x 148mm x 142mm [Width x Depth x Height].
Size [cm]: 5cm x 14.8cm x 14.2cm [Width x Depth x Height].

2 x 1/2 inch x 400mm (40cm) flex pipe connections.
Deck mount drill hole diameter: 35mm (3.5cm).
Requires minimum 1.0 bar operating pressure.
Refer to the technical diagram for complete technical dimensions.
Download the Installation Instruction PDF File from the Additional Info Section.

Info / Size (mm)

Tap
Width: 50 mm
Depth: 148 mm
Height: 142 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Range
: Life
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upwards
⤷ Colour
: Chrome
⤷ Country of Origin
: UK
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve/Cartridge Type
: Ceramic Disc
⤷ Base To Spout
: 112

⤷ Spout Reach
: 112
⤷ Overall Height
: 142
⤷ Width
: 36
⤷ Minimum Operating Pressure (Bar)
: 1.0
⤷ Water Saving
: Yes
⤷ Flow Rates (l/min)
: 4.6
⤷ Handle Style
: Lever Handle
⤷ WRAS Approved
: Yes
⤷ Waste Included
: Sold Separately
⤷ Compliance/Approvals/Standard
: WRAS
⤷ Barcode
: 5057199918093
⤷ Product Type
: Basin Mixer Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £169.00 2 Working Days Approx QS Supplies

3 Features Included In This Product Explained

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...
