Vado Notion Slimline Chrome Mono Basin Mixer Tap

Vado Notion NOT-200/SB-C/P Details

The Vado Notion Slimline Mono Basin Mixer Tap is a solid, long-lasting unit fitted with the H2Eco flow regulator that allows a flow of up to 5 litres per minute at 3 bar water pressure. A WRAS approved a product that does not come with waste, but universal options are available for purchase separately if needed. It is also fitted with a ceramic cartridge and a design that includes 2 ½ inch nut x 550mm flexi pipe connections; this simple deck-mounted style is controlled via single lever operation and works smoothly with at least 1 bar of water pressure behind it.

Available in 2 variants: Without Waste, With Waste.
Size [mm]: 48mm x 152mm x 148mm [Width x Depth x Height].
Size [cm]: 4.8cm x 15.2cm x 14.8cm [Width x Depth x Height].
Smooth bodied.
Single lever operation.
Deck-mounted installation.
Ceramic cartridge - C-010-N25.
2 x 1/2 inch nut x 550mm (55cm) Flexi pipe connections.

Deck mount drill hole diameter: 35mm (3.5cm).
H2Eco 5 l/m flow regulator fitted as standard.
Flow rate at 3 bar pressure: 5 litre/min.
Minimum 1.0 bar operating pressure recommended.
Suitable for high water pressure system.
Refer to the technical drawing for complete size details.
Download the Installation Instruction PDF File from the Additional Info Section.

Info / Size (mm)

Tap
Width: 33 mm
Depth: 152 mm
Height: 148 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Tap Body Shape
: Square
⤷ Handle Position
: Upwards
⤷ Range
: Notion
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 15 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Disc
⤷ Base To Spout
: 105

⤷ Spout Reach
: 152
⤷ Overall Height
: 148
⤷ Width
: 48
⤷ Minimum Operating Pressure (Bar)
: 1
⤷ Water Saving
: Yes
⤷ Diameter of Waste Connection
: 1 inch 1/4
⤷ Flow Rates (l/min)
: 5 1/ min at 3 bar
⤷ Handle Style
: Lever Handle
⤷ WRAS Approved
: Yes
⤷ Waste Included
: Sold Separately
⤷ Barcode
: 5052120179215
⤷ Product Type
: Basin Mixer Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £201.50 2 Working Days Approx QS Supplies

3 Features Included In This Product Explained

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...
