Bristan Infrared Temperature Control Chrome Finish Basin Spout


RRP: £484.00


2 Working Days Approx.

Not Yet Rated No Rating

Shipping: £7.95

Key Features
  • Constructed using high-quality brass material
  • WRAS approved tap
  • Automatic switch-off supports water saving
  • BREEAM compliant
  • One-year guarantee from the manufacturer against any manufacturing defects.
SKU Code: QS-V80648


Bristan Infrared IRBS4-CP Details

The Bristan Infrared Temperature Control Basin Spout is a WRAS approved tap that is suitable for use with high pressure systems that work between a minimum of 1 bar and a maximum of 5 bar of water pressure for smooth operation. Constructed from high-quality brass material and coated in a lovely chrome finish, this contemporary and stylish design offers non-touch controls and uses infrared sensing technology that turns the unit on and off for operation when a user is, or is not, present. Complete with temperature control and a maximum temperature stop for safety, this product also includes an automatic shut-off to save as much water as possible as well.

  • The manufacturing code of these products is IRBS4-CP.
  • It comes in a fabulous chrome finish.
  • Contemporary and stylish design.
  • Size in [mm]: 70mm x 150mm x 175mm [Width x Height x Depth].
  • Size in [cm]: 7cm x 15cm x 17.5cm [Width x Height x Depth].
  • Base to spout: 122mm (12.2cm).
  • Handle type: Infra-red.
  • Inlet connections: G 1/2 inch.
  • Suitable for high water pressure.
  • Required minimum 1.0 bar to maximum 5.0 bar water pressure.
  • Maximum hot water temperature: 65°c.
  • Maximum dynamic pressure: 5 bar.
  • Maximum static pressure: 10 bar.
  • Flow type: Single flow.
  • Power Rating: AC: 220V-240V, 50/60HZ DC: 6V (4x AA Alkaline Batteries (Not supplied).
  • Non-touch control, using infrared sensing technology.
  • Temperature control for user comfort.
  • Maximum temperature stop for user safety.
  • Refer to the technical diagram for the complete technical dimension.
  • Download the Installation Instruction PDF File From The Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Water Activation
  • : Motion Sensor
  • ⤷ Tap Body Shape
  • : Round
  • ⤷ Colour
  • : Chrome
  • ⤷ Warranty/Guarantee
  • : 1 Year
  • ⤷ Material
  • : Brass
  • ⤷ Installation Type
  • : Deck Mounted
  • ⤷ Base To Spout
  • : 122
  • ⤷ Inlet Connections
  • : G 1/2 Inch
  • ⤷ Minimum Operating Pressure (Bar)
  • : 1.0 Bar
  • ⤷ Flow Rates (l/min)
  • : 5.4 (l/min) at 3 bar
  • ⤷ Power Source
  • : Battery
  • ⤷ Sensor Type
  • : Infra-Red
  • ⤷ Compliance/Approvals/Standard
  • ⤷ Barcode
  • : 5014868045306
  • ⤷ Product Type
  • : Sensor Tap

Additional Info & Downloads

Total: £259.75 2 Working Days Approx QS Supplies

1 Features Included In This Product Explained

WRAS Approved Product

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
