Idael Standard I.Life-B Vessel Rectangular White Ceramic Countertop Basin, T573801

Ideal Standard I.Life-B Details

MFC: T573801

Idael Standard I.Life-B Vessel Rectangular White Ceramic Countertop Basin.

Key Features

✔Standards = EN 14688
✔It Comes in a White Finish
✔Manufactured using Ceramic Material
✔Lifetime Guarantee from Ideal Standard Against Manufacturing Defects

Choice of Width: 500mm and 605mm
Choice of Taphole: 0 and 1 Taphole
Choice of Overflow: With or Without Overflow
Fixing Set
Download the Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section
Refer to the Technical Diagram for Complete Technical Details
Detail for 500mm No Taphole Basin:
Size in [mm]: 500 x 420 x 130mm [Width x Depth x Height]
Size in [cm]: 50 x 42 x 13cm [Width x Depth x Height]
Overall Height: 145mm (14.5cm)
Weight: 13 Kg
Detail for 500mm 1 Taphole Basin:
Size in [mm]: 500 x 420 x 130mm [Width x Depth x Height]
Size in [cm]: 50 x 42 x 13cm [Width x Depth x Height]
Overall Height: 145mm (14.5cm)
Weight: 13 Kg
Supplied with 1 Taphole Basin
Detail for 605mm 1 Taphole Basin:
Size [mm]: 605 x 420 x 150mm [Width x Depth x Height]
Size [cm]: 60.5 x 42 x 15cm [Width x Depth x Height]
Weight: 15 Kg
Supplied with 1 Taphole Basin
The Tap and Waste Shown in the Image are not Included

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: I-Life-B
⤷ Basin Underside
: Unglazed
⤷ Coating
: Without Coating
⤷ Colour
: White
⤷ Weight in kg
: 13
⤷ Shape
: Rectangular
⤷ Warranty/Guarantee
: Lifetime
⤷ Material
: Ceramic
⤷ Theme
: Modern
⤷ Waste Included
: Sold Separately
⤷ Projection (Depth)
: 420
⤷ Width
: 500

⤷ Height
: 145
⤷ Inner Bowl Width
: 470
⤷ Inner Bowl Depth
: 390
⤷ Distance rear edge to centre of waste hole
: 210
⤷ Distance rear edge to centre of tap hole
: 65
⤷ Number of bowls
: 1
⤷ No. of Tap Holes
: 0
⤷ Tap Hole Position
: Centre
⤷ Compliance/Approvals/Standard
: BS EN 14688
⤷ Tap Hole Size
: Ø35
⤷ Barcode
: 8014140521976
⤷ Product Type
: Counter Top Washbasin

Additional Info & Downloads

Download the Customer Data Sheet for 500mm No Taphole Basin Pdf File Download the Customer Data Sheet for 500mm 1 Taphole Basin Pdf File Download the Customer Data Sheet for 605mm 1 Taphole Basin Pdf File

Technical Images

Idael Standard I.Life-B Vessel Rectangular White Ceramic Countertop Basin

500mm - 0 Tap Hole without Overflow

500mm - 1 Tap Hole with Overflow

600mm - 1 Taphole

£132.09

RRP: ~~£225.07~~

STOCK AVAILABLITY: 5 Working Days Approx

QS Supplies

2 Features Included In This Product Explained

Fireclay

It is incredibly hard-wearing and has an everlasting shiny surface. They have a high heat resistance (1600°C) and are chemical resistant, non-porous, and hygienic.

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.
