Imex Ravine Back To Wall Freestanding Style Bath

Finishes: White & Matt Black

£930.00

RRP: £1550.00

STOCK AVAILABLITY:

6 Working Days Approx.

4.0 out of 5 4.0 out of 5

Based on 3 Ratings.

Shipping: £39.99

Select Bath
You've Selected: OP-240740 - 1500 x 750mm White
Key Features
  • Solid core reinforcement for rigidity & strength
  • 7 Layers of bonded fiberglass core matting
  • Construction using high quality acrylic material
  • Multilayer core construction keeps water hotter for longer
  • 25 years guarantee from the manufacturer against any manufacturing defects
SKU Code: QS-V110159

MFC Code: PB1016A

Ravine PB1016A Details

Imex Ravine Back To Wall Freestanding Style Bath.

  • Available in 2 finishes: White And Matt Black
  • Available in 2 sizes - 1500 x 750mm, 1700 x 810mm
  • Fully reinforced back to wall freestanding style bath
  • Hand finished in the UK
  • For complete size details, please refer to the technical drawing
  • Download the Aftercare Guide PDF file from the additional info section
  • Specification Of 1500 x 750mm Bath
  • Size in [mm]: 1500mm x 750mm x 440mm [Length x Width x Depth]
  • Size in [cm]: 150cm x 75cm x 44cm [Length x Width x Depth]
  • Height: 570mm [57cm]
  • Specification Of 1700 x 810mm Bath
  • Size in [mm]: 1700mm x 810mm x 420mm [Length x Width x Depth]
  • Size in [cm]: 170cm x 81cm x 42cm [Length x Width x Depth]
  • Height: 570mm [57cm]
  • Headrest - [See Option]
  • Waste and overflow shown in the image are not included

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Position of Drain
  • : Centered Waste
  • ⤷ Bath Type
  • : Double-Ended
  • ⤷ Range
  • : Ravine
  • ⤷ Interior Shape
  • : Rectangular
  • ⤷ External Length
  • : 1500
  • ⤷ External Width
  • : 750
  • ⤷ Tub Depth
  • : Internal - 440
  • ⤷ Height Including Feet or Panel
  • : 570
  • ⤷ Colour
  • : White
  • ⤷ Internal Bottom Length
  • : 1000
  • ⤷ Internal Bottom Width
  • : 430
  • ⤷ Internal Top Length
  • : 1440
  • ⤷ Internal Top Width
  • : 640
  • ⤷ Height of Rim
  • : 80
  • ⤷ Distance Tub edge to centre of drain hole
  • : 842
  • ⤷ Distance Top edge to centre of overflow hole
  • : 76
  • ⤷ Diameter of Drain hole
  • : 50
  • ⤷ Rim Width
  • : 30
  • ⤷ Shape
  • : D-Shaped
  • ⤷ Warranty/Guarantee
  • : 25 Years
  • ⤷ Material
  • : Acrylic
  • ⤷ No. of Bathers
  • : 2
  • ⤷ Theme
  • : Modern
  • ⤷ Waste Included
  • : Sold Separately
  • ⤷ Barcode
  • : 5057199981769

Additional Info & Downloads

Download PDFDownload the Aftercare Guide Pdf File

Add-Ons

Optional Waste Common
Optional Waste Common

Below is the list of waste compatible with the bath. Select the appropriate bath waste as required. The image shown is for illustration purposes only.

Bath-Headrest
Bath-Headrest

Soft & high-quality headrest for the bath! Please Note: The image shown is for illustration purposes only.

£930.00
RRP: £1550.00
STOCK AVAILABLITY: 6 Working Days Approx
QS Supplies

2 Features Included In This Product Explained

Lucite Acrylic

Lucite Acrylic

It is a high-quality acrylic resin developed by DuPont in 1937 and is one of the top-quality materials available in today's market. It replaced glass as it is less breakable, offers high strength and resistance to UV rays, moisture and wind, and is easy to clean. It is also incredibly flexible and can create the best products.

With / Without Overflow

With / Without Overflow

An overflow is a small hole or opening at the upper part of a sink, basin, bidet or tub that drains away water upon reaching its level so that no water is spilt. When a basin or bath does not come with this design feature, it is called 'without-overflow' and will need a compatible drain.
