Nuie Ava 385 x 613mm Rimless Closed Coupled Toilet With Soft Close Seat



5-7 Working Days Approx

4.0 out of 5 4.0 out of 5

Based on 1 Ratings.

Shipping: £20.00

Key Features
  • Includes Pan, Cistern and Seat
  • Constructed using high-quality vitreous china
  • CE certified product
  • Five-years guarantee from the manufacturer against any manufacturing defects
SKU Code: QS-V108378

MFC Code: NCG451

Nuie Ava NCG451 Details

Nuie Ava Rimless Close Coupled Toilet with Soft Close Seat is a stylish and useful accessory perfect for use in any public bathrooms anywhere. It is offered in a glossy white finish made from amazingly high-quality vitreous china. These units look lovely hung alongside a compatible bidet. With a completely secure wall-mounted installation that saves precious space, this Pan from Nuie is a must-have for every bathroom.

The product includes a Pan, Cistern, and Seat and carries a mark of quality and reliability in the form of a CE certification. Remarkably easy to maintain and clean from top to bottom, this unit includes a water saving dual flush. This product also assures you the highest satisfaction of hygiene as the rimless design leaves no room for bacteria to hide and thrive.

  • The manufacturing code of this product is NCG451.
  • Overall size [mm]: 385mm x 613mm x 795mm [Width x Projection x Height].
  • Overall size [cm]: 38.5cm x 61.3cm x 79.5cm [Width x Projection x Height].
  • Modern soft square curves create a clean, neat design.
  • Supplied without fixing.
  • Refer to the technical drawing for more technical specifications.
  • Pan:.
  • Edge style: Rimless.
  • Size [mm]: 385mm x 408mm [Width x Height].
  • Size [cm]: 38.5cm x 40.8cm [Width x Height].
  • Projection: 613mm (61.3cm).
  • Pan type: Flush to wall.
  • It comes in a white finish.
  • Weight: 35.
  • Trap Style: P Trap.
  • Cistern:.
  • Size [mm]: 385mm x 387mm [Width x Height].
  • Size [cm]: 38.5cm x 38.7cm [Width x Height].
  • Operating Type: Push-button.
  • Lever Type: Plastic chrome plated.
  • Dual flush cistern.
  • Full Flush - 6 Ltrs and Half flush - 3 Ltrs.
  • Seat:.
  • Soft closed toilet seat.
  • Shape: Square.
  • Material: Urea.
  • It comes with metal hinges.
  • Installation type: Top fix hinges.
  • Seat fixing centres: 156mm (15.6cm).
  • Download the Customer Data Sheet PDF File from the Additional Info Section.

Info / Size (mm)

  • Toilet
  • Width: 385 mm
  • Projection: 613 mm
  • Height: 795 mm

Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Ava
  • ⤷ Toilet Design
  • : Back To Wall
  • ⤷ Coating
  • : Without Coating
  • ⤷ Colour
  • : White
  • ⤷ Weight in kg
  • : 35
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Material
  • : Vitreous China
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Floor Standing
  • ⤷ Pan Width
  • : 385
  • ⤷ Pan Height
  • : 415
  • ⤷ Toilet Overall Height
  • : 795
  • ⤷ Projection (Depth)
  • : 613
  • ⤷ Rimless Bowl
  • : Yes
  • ⤷ Cistern Included
  • : Yes
  • ⤷ Cistern Width
  • : 385
  • ⤷ Cistern Height
  • : 387
  • ⤷ Flush Type
  • : Dual
  • ⤷ Full Flush Volume in litres
  • : 6
  • ⤷ Half Flush Volume in litres
  • : 3
  • ⤷ Flush Mechanism
  • : Push Button
  • ⤷ Cistern Lever Or Button Placement
  • : Top
  • ⤷ Outlet
  • : Horizontal
  • ⤷ Configuration
  • : Pan | Cistern | Seat
  • ⤷ Seat Included
  • : Yes
  • ⤷ Seat Type
  • : Soft Close
  • ⤷ Seat Finish
  • : White
  • ⤷ Compliance/Approvals/Standard
  • : CE
  • ⤷ Barcode
  • : 5056462683386
  • ⤷ Bowl Shape
  • : Square
  • ⤷ Product Type
  • : Closed Coupled
  • ⤷ Seat Post Hole Centers
  • : 156
  • ⤷ Front Of Bowl To Centre Of Seat Holes
  • : 428
  • ⤷ Base to centre of outlet
  • : 182

Additional Info & Downloads

Total: £139.66 5-7 Working Days Approx QS Supplies

5 Features Included In This Product Explained

Soft-Close Seat

Soft-Close Seat

Soft-closing seats are a new alternative to classic toilet seats. Their modern design allows them to close slowly, while their controlled manner of closing does not require you to assist them. It also shuts automatically, allowing it to come down at a pace that does not make much noise.



A rimless toilet does not have a brim at its edge, from which the water usually flows when you flush. Instead of flowing from the top, such toilets shoot water towards its edge and around it, allowing no missing spots with filth remaining after a flush. These toilets also remove any spaces for germs to hide and breed, providing a hygienic alternative for your bathroom.

Horizontal Outlet

Horizontal Outlet

When the pan has piping at the back, inside the wall, it is called a horizontal outlet toilet or pan. As the cisterns are concealed or placed against the wall, most plumbing is hidden out of sight.



It is a plastic moulded under high pressure and offers durability and rigidity with scratch and chemical resistance. It is also antimicrobial and anti-bacterial.

CE Certified Product

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.
