Duravit White Tulip Bidet Mixer Tap With Pop Up Waste

Duravit White Tulip WT2400001010 Details

Duravit White Tulip Single Lever Bidet Mixer Tap With Pop Up Waste suits modern lifestyles perfectly and comes with a sleek design that requires minimal maintenance. It comes with value-adding features such as a ceramic cartridge, a Pop-up waste and a single lever design. Extremely safe for daily use, it comes with a height of 168mm and a width of 48mm. Ideal for high water pressure systems, it requires min 3.0 bar and max. 5.0 bar operating water pressure. Designed by Philippe Starck, it is backed by a 5-year warranty from Duravit against manufacturing defects.

The manufacturing code of the product is WT2400001010.
It comes with Pop-up waste.
Single Lever design.
Ceramic Cartridge included.
Size [mm]: 48mm x 168mm [Width x Height].
Size [cm]: 4.8cm x 16.8cm [Width x Height].
Projection: 144mm (14.4cm).
The centre of the inlet to the centre of the outlet: 111mm (11.1cm).
Base to spout: 65mm (6.5cm).

3/8inch flexible hose connection.
Normal spray function.
Connection size DN15.
It comes in a chrome finish.
Maximum temperature can be adjusted on installation.
Suitable for high-pressure water system.
Required min 3.0 bar and max. 5.0 bar operating water pressure.
Refer to the technical drawing for more technical specifications.

Info / Size (mm)

Tap
Pipe Centre: 111 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting/Tilting
⤷ Tap Body Shape
: Round
⤷ Handle Position
: Upward
⤷ Range
: White Tulip
⤷ Colour
: Chrome
⤷ Country of Origin
: Germany
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Ceramic Disc Cartridge
⤷ Base To Spout
: 65

⤷ Spout Reach
: 111
⤷ Overall Height
: 168
⤷ Width
: 48
⤷ Depth
: 144
⤷ Inlet Connections
: G 3/8
⤷ Minimum Operating Pressure (Bar)
: 3
⤷ Waste Type
: Pop uP
⤷ Diameter of Waste Connection
: 63
⤷ Flow Rates (l/min)
: 3 Bar - 4.5
⤷ Handle Style
: Lever
⤷ Waste Included
: Yes
⤷ Barcode
: 8000177309175
⤷ Product Type
: Bidet Mixer Tap

Additional Info & Downloads

Download the Installation Instruction Pdf File

Total: £426.10 5-7 Working Days Approx QS Supplies

2 Features Included In This Product Explained

Ceramic Disc Cartridge

It has two ceramic discs, one fixed in place and the other moveable with the tap or valve handle. It is the most common technology used in modern tapware as it offers unmatched advantages such as no leaks and drips and saves on water and money.
Read more...

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.
