Crosswater Bauhaus Edge Flat Panel Designer Towel Rail - 500mm Wide




RRP: £225.00


3 Working Days Approx

4.0 out of 5  4.0 out of 5
5 out of 5 customers rated 80%

Review this Product

Shipping: £6.95

Available Height Step 1

Available Finishes Step 2

Compatible Valves Step 3

Summer Heating Element Step 4

Please Note all the measurements are in 'mm'
Colour Anthracite
Shape Straight
Warranty/Guarantee 15 Years
Material Steel
Theme Modern
Installation Type Wall Mounted
Projection (Depth) 100
Width 500
Height 720
Fixings included Yes
Orientation Vertical
Compliance/Approvals/Standard Round EN 10234 / EN ISO 4287, Flat Tube EN 10233 / EN ISO 4287, D Profile EN 10233 / EN ISO 4287
BTU Output 1108
Watts 325
Tapping / Pipe Centres 450
Valves Included Sold Separately
Heating Element Included Sold Separately
Volume (ltrs) 4.2
Design Flat Panel

Crosswater Bauhaus Edge ED50X72A DETAILS

Crosswater Bauhaus Edge 500mm Wide Flat Panel Towel Rail is offered in a chic and remarkably stylish design that is available for purchase in several different heights to choose from. Ideal for installation within any compatible entrance hall, kitchen or bathroom space; this product can also include a contemporary, radiator valve set and heating alongside it as well if desired, available separately. Featuring an impressively short response time, once this unit is turned on, it takes only minutes to warm up even a huge room or area, anywhere.

  • Straight towel warmer
  • Pipe Centres : 450mm
  • Width: 500mm
  • Projection between : 75mm - 100mm
  • Manufactured from high grade mild steel confirming to EN 10305
  • Fitted with 1/2 inch BSP female connections
  • Supplied with complete wall fixings and manual air vent
  • Geometrical and surface finish - Round EN 10234 / EN ISO 4287, Flat Tube EN 10233 / EN ISO 4287, D Profile EN 10233 / EN ISO 4287
  • Radiator valves and Heating elements [Optional]
  • Refer technical diagram for more technical detail
  • 15 years of guarantee from manufacturer.

Technical Images

Detail For Towel Rail
Width mm Height mm MFC Finish Weight Kg Litres BTU Watts Heating Element Required
500 720 ED50X72A Anthracite 7.1 4.2 1108 325 150w
500 1150 ED50X115A Anthracite 11.3 7.4 1665 488 300w
500 1420 ED50X143A Anthracite 14.1 8.9 2084 611 600w
500 720 ED50X72C Chrome 7.1 4.2 692 203 150w
500 1150 ED50X115C Chrome 11.3 7.4 1023 300 300w
500 1420 ED50X143C Chrome 14.1 8.9 1262 370 600w
Detail For Valves
Square Angled Valve RADVA2
Round Angled Valve RADVA1
Detail For Electric Heating Elements
300W Electric Element RADX350
600W Electric Element RADX700
