  • Size: Width 1000mm x Height 1950mm
  • 8mm Toughened safety clear glass
  • Mershield Stayclear - easy clean protected glass
  • Frameless design
  • Minimalist designer hinges
  • Space saving solution
  • Wetroom compatible
  • Reversible design [left or right hand installation]
  • Door opening size: 780mm
  • Width of panel when folded: 475mm
  • Adjustment in recess: 960 - 990mm [minimum - maximum]
  • Adjustment with side Panel: 955 - 975mm [minimum - maximum]
  • Manufactured in accordance with ISO 9002 and EN 14428 and utilise toughened safety glass to EN 12150
  • Power shower approved - will retain water under normal showering conditions
  • Supplied complete with full installation instructions and the necessary fixings
  • Manufacturing code of this product is M87231
  • Lifetime guarantee from the manufacturer
  • Side panel, brassware and tray shown in the image are not included
  • Side panel optional [See Option]
  • Tray with waste optional [See option]
  • Panel kit with legs, extension profile and enclosure wiper optional [See option]
  • For installation instructions, download PDF from technical tab.
Please Note all the measurements are in 'mm'
Warranty/Guarantee Lifetime
Installation Type Corner, Recess
Width 1000
Configuration Door Only
Height 1950
Door Type Bi-Fold
Frame Design Frameless
Glass Type Clear
Glass Thickness 8
Number Of Doors 1
Side Panel Included Sold Separately
Door Adjustment Recess: 960 - 990, With Side Panel: 955 - 975
Tray Included Sold Separately
Easy to Clean Glass Yes
Power Shower Proof Yes
Handle Included Yes
Wetroom Compatible Yes
Tray Compatible Yes

Mershield Stayclear acts as a protective coating which when applied to glass, helps the glass to remain shiny and new without the need for tiresome cleaning. When cleaned correctly it helps prevent the build up of limescale and soap deposits making the shower glass "Easy to Clean".
Please note: Optional Side Panel must be fixed to the moving panel i.e. door closing side of the enclosure.

Merlyn 8 Series Frameless Hinged Bifold Shower Door 1000mm

QS-V19312 MFC CODE: M87231

  • Door
  • Width: 1000 mm
  • Height: 1950 mm



2-3 Working Days Approx

3.9 out of 5 3.9 out of 5

12 out of 12 customers rated 78%

Review this Product

Shipping: £29.95


The Merlyn 8 Series Bi-fold Shower Door adds a touch of elegance and flair to the modern interiors while being a great space-saving solution. The door equipped with minimalist, designer hinges splits vertically and folds onto itself allowing for much greater access, and it is not outward opening, so it fits easily into smaller bathrooms. This frameless fixture creates an enclosure which spurs you into starting your day with a good, refreshing shower and is designed to provide you with a comfortable and relaxing showering experience. It is expertly crafted from toughened safety glass, allowing for an added measure of protection and durability. The reversible door allows for installation where left or right-handed access is required for full versatility.

+  Read what's included.. & options available

8 Series Frameless Side Panel Option
8 Series Side Panel

Extra 20mm Extension Profile
Extension Profile

MStone Shower Tray
Shower Tray

Panel Kit With Legs For Merlyn Tray
Shower Tray Panel Kit

Truestone Shower Tray With 90mm Fast Flow Waste
Truestone Shower Tray

Level25 Shower Tray With 90mm Fast Flow Waste
Level25 Shower Tray

Enclosure Wiper
Merlyn Shower Wiper

Sizes Available
Other Sizes / Finishes / Variations Available.
QS Code Finish Size / Difference MFC Code
QS-V8969 - 760mm M87111
QS-V30376 - 800mm M87211
QS-V78560 - 900mm M87221


Total: £446.87 2-3 Working Days Approx QS Supplies

You've Selected which adds to a total of



Rate this Item.:

Questions & Answers

  Submit Your Questions 3 Questions Asked

Have a question about this item? Ask our tech team. We aim to reply within 72 hours. If you want to know get answers fast, please call us on 0116 251 0051

Deborah Asked :
Hi, please, can you confirm that the merlyn 8 series bi-fold shower door 1000mm can be fitted in a walk in shower? I want to check that when the bi-fold door is fully extended, it does not need to meet up with another panel. Hope that makes sense! Thank you.

Answered By QS Team :
The bi-fold can be used on its own, it does not need to meet another panel. See the following link: https://merlynshowering.com/product/8-series-folding-showerwall/. Hope that answers your question.

Was this answer helpful? Yes - No

taslim Asked :
I am interested in the Merlyn shower door MFC code: M87231. can you fix the doors in between 2 walls? Your picture shows it with a side panel. I just want the doors. And can you use it in a wetroom with a power shower? Thank you. Regards Taslim

Answered By QS Team :
This shower door is suitable to fit in a recess between two walls. It is also suitable for a wetroom situation so this would suit your requirements. Hope this helps.

Was this answer helpful? Yes - No

Michael Asked :
if I purchase the bi-fold door and an 800mm end panel, do I need any fixing angles etc. to fit the enclosure?

Answered By QS Team :
You have everything you need to fit this enclosure. The magnetic seal for the Side panel is included in the box M82102 and the Seal for the Bifold Door is in M87231.

Was this answer helpful? Yes - No
