Nuie Mayford 500mm Gloss White Back-To-Wall WC Unit And Concealed Cistern

Nuie Mayford NVS142 Details

Nuie Slimline Mayford 500 x 202mm Gloss White Back to Wall WC Unit and Concealed Cistern is a charming compact unit that seamlessly and subtly enhances the bathroom's overall look. Its generous dimensions and excellent craftsmanship make it a much sought-after addition for modern settings. Uniquely designed, it is suitable with a back-to-wall WC pan and comes with a 5-year guarantee from the manufacturer. The concealed cistern frees up the space, so it is just what your small bathrooms and en-suites need. It is also suitable for homes with the elderly, or those with limited mobility as you can place the flush within easy reach of the user and all the ugly pipework is tucked away from sight.

Former Known as Premier Sienna Gloss White Back-To-Wall WC Unit And Concealed Cistern - NVS142.
Size [mm]: 500mm x 202mm x 770mm [Width x Projection x Height].
Size [cm]: 50cm x 20.2cm x 77cm [Width x Projection x Height].
Suitable for use with back-to-wall WC pan.
Cabinet thickness: 16mm (1.6cm).
Fascia thickness: 18mm (1.8cm).

Supplied rigid for easy installation.
Contemporary design.
The manufacturing code of this is NVS142.
Optional Products: WC pan and Seat.
Download Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section.
Refer to the technical drawing for more technical specifications.

Info / Size (mm)

Unit
Width: 500 mm
Depth: 202 mm
Height: 770 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Mayford
⤷ Colour
: White
⤷ Warranty/Guarantee
: 5 Years
⤷ Theme
: Modern
⤷ Installation Type
: Floor Mounted
⤷ Cistern Included
: Yes
⤷ Width
: 500
⤷ Depth
: 202
⤷ Height
: 770

⤷ Compliance/Approvals/Standard
: FSC Certification
⤷ Barcode
: 5055369002580
⤷ Product Type
: Back To Wall Unit
⤷ Furniture Material
: MDF and MFC
⤷ Pre-assembled
: Yes
⤷ Worktop Included
: Yes
⤷ Worktop Colour
: Same As Unit
⤷ Toilet Included
: Sold Separately

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instruction Pdf File

Customise Your Product

Back-To-Wall WC

A stylish, strong, and durable back-to-the-wall toilet pan! Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-44594 - W355mm x D520mm x H 410mm Back-To - Wall WC Pan + £66.73

Optional Toilet Seat

Solid and durable toilet seat for WC pan. This toilet seat comes with quick release fixing for easy cleaning. Please Note: The image shown is for illustration purposes only.

No Option Selected
OP-44595 - Round Soft Close Toilet Seat With Bottom Fixing + £17.78

Total: £98.60 3-4 Working Days Approx QS Supplies

3 Features Included In This Product Explained

Rigid Furniture - Pre-Assembled

Rigid or pre-assembled furniture is any bathroom unit that is ready to install. These arrive entirely constructed with pre-drilled holes and labelled parts making the furniture installation process quick and easy. It helps you save money on labour, and you get a higher-quality product. These are also an excellent choice for anyone looking for a new storage unit that fits their bathroom decor.

Cam & Dowel Method

It is a woodworking process in which a dowel or wooden pin is fit into a pre-carved hole in the opposite pieces of wood to create a strong joint. The resulting piece of furniture has a rigid carcass with a neat finish and removes the need for glue or nails for adhesion.

FSC Certified

Any product with this logo is made of wood from well-managed, sustainable forests. Its full form is certified by the Forest Stewardship Council. By buying such products, you are supporting responsible forestry.

Reviews & Ratings

By: Moirah From : CARLISLE Overall Rating: Date: January 3, 2018 replacement toilet

Very good support from the people at the other end of the phone regards specific product details. Delivery no problem and the unit is now fitted and looks the part. The plumber commented on how good it looked, thank you

Helpful?

Quality:

Style

Value for Money

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Simon Asked :
Does this product include the toilet pan and seat/lid?

Answered By QS Team

The product includes back to wall unit and concealed cistern. WC Unit and seat are available as optional products in the "Customise Your Product" tab. The vanity unit with the basin is not included in the product.
