Bristan Gummers 22mm Chrome Tmv3 Thermostatic Mixing Valve With Isolation

Bristan Gummers MT753CP-ISO Details

This chrome-plated robust thermostatic mixing valve from Bristan Gummers comes with isolation at mixing point, making it supremely easy to clean and service. With high and low-pressure bath fill applications and water pressure between 0.1 bar and 5 bar, the valve would be an asset in any bathroom. Constructed for safety with a pre-set temperature of 43 degrees C, a maximum temperature of 80 degrees C and a self-activated turn-off system in the event of water failure 106mm high valve is also guaranteed by Bristan for 12 months against any manufacturing flaw.

Manufacturing code of this product: MT753CP-ISO.
It comes in a fabulous chrome finish.
Size in [mm]: 238mm x 106mm [Width x Height].
Size in [cm]: 23.8cm x 10.6cm [Width x Height].
High and low-pressure bath fill applications.
Check valves and serviceable filters as standard.
Operates at a maximum pressure differential of 10:1.
Part G compliant.

22mm inlet and outlet connections.
Minimum pressure drop: 0.1 bar.
5.0 bar maximum dynamic pressure.
Maximum static pressure: 10 bar.
Factory preset temperature: 43ºC.
Maximum hot water supply temperature: 80ºC.
Refer to technical image for the technical dimension.
Download the Installation Instruction PDF File From The Additional Info Section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 1 Year
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Overall Height
: 106
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Handle Style
: Knob

⤷ WRAS Approved
: Yes
⤷ Temperature Control
: Thermostatic
⤷ TMV3 Approved
: Yes
⤷ Number of Handles
: 1
⤷ Plumbing Option
: Exposed
⤷ Overall Width
: 238
⤷ Maximum Operating Pressure (Bar)
: 5

Additional Info & Downloads

Download the Installation Guide Pdf File

Total: £80.09 2 Working Days Approx QS Supplies

2 Features Included In This Product Explained

WRAS Approved Product

WRAS Approval means that the particular water fitting or product complies with or meets the requirements specified by the Water Supply (Water Fittings) Regulations or Scottish Byelaws. Such compliance is based on certain tests that prove that the product or fitting does not cause waste, misuse, contamination or undue consumption of the public water supply system in the UK.
Read more...

TMV3 Approved Product

TMV3 approval means a thermostatic valve is certified and approved for use in healthcare and commercial situations.
