Reina Serena Mild Steel Designer Radiator 500mm Wide

£98.35

STOCK AVAILABILITY

5 Working Days Approx

Not Yet Rated No Rating

Shipping: FREE* Check Postcodes

Product Variants
Select Finish Step 1
Select Height Step 2
Select Radiator Type Step 3
Select Heating Element Type Step 4
Select Essential Accessories Step 5
SKU Code: QS-V20831

MFC Code: RND-SRN5050A

Reina Serena RND-SRN5050A Details

Another minimalistic yet functional appliance to come out of the stable of Reina is the Serena Designer Radiator. It has a lovely Anthracite finish and is made of high quality mild steel. Bold, clean, straight lines define the look of this heating appliance. It can be embedded in any surrounding due to its basic, standard appearance. The heat emitted from this radiator is enough to transform a cold, moist, clammy room into a warm, dry, pleasant hangout.

It is compatible with all heating systems - Central, Electric and Dual Fuel. Heavy-duty steel construction means that durability will not be a problem, and with its simple and minimalistic look, this one will surely grab your attention. A set of brackets accompanies this purchase. The manufacturer has thrown in a 5-year guarantee for good measure.

Key Features
  • EN 442 Compliant product
  • Supplied with air vent and end plug
  • Manufactured using mild steel material
  • Five-year guarantee from Reina against manufacturing defects
  • Choice of different finishes: Anthracite and Chrome - [Optional]
  • Available in different heights: 500mm, 800mm and 1200mm - [Optional].
  • Available variants: Central heating, Dual Fuel and Electric - [Optional].
  • Choice of heating element available - [Optional].
  • Width: 500mm (50cm).
  • Pipe centres: 470mm (47cm).
  • Wall to pipe centres: 65-80mm (6.5-8cm).
  • Distance from wall: 80-95mm (8-9.5cm).
  • Suitable for central, electric and dual fuel heating systems.
  • Brackets for radiator included.
  • For the Dual Fuel and Electric model, Heating Elements are highly recommended in combination with T-Piece.
  • For Electric models, Optional Liquid Filling is required with the heating element.
  • Valves, sleeving kit and chrome pipe kit [Optional].
  • The image shown is for illustration purposes only.
  • Download the Heating Element Manual Instructions and Details PDF File from the Additional Info Section.
  • Refer to the technical diagram for complete technical dimensions.
  • The valves shown in the image are not included.

Please Note: The appropriate wattage of the element (if selected) will be decided by the manufacturer, once the order is placed.


Technical Specifications

Please note all the measurements are in 'mm'
  • ⤷ Range
  • : Serena
  • ⤷ Colour
  • : Anthracite
  • ⤷ Shape
  • : Straight
  • ⤷ Country of Origin
  • : Turkey
  • ⤷ Warranty/Guarantee
  • : 5 Years
  • ⤷ Material
  • : Steel
  • ⤷ Theme
  • : Modern
  • ⤷ Installation Type
  • : Wall Mounted
  • ⤷ Projection (Depth)
  • : 80-95
  • ⤷ Width
  • : 500
  • ⤷ Height
  • : 500
  • ⤷ Orientation
  • : Vertical
  • ⤷ Compliance/Approvals/Standard
  • : EN 442
  • ⤷ Barcode
  • : 5057199127174
  • ⤷ BTU Output
  • : 70°C - 1082
  • ⤷ Watts
  • : 70°C - 317
  • ⤷ Tapping / Pipe Centres
  • : 470
  • ⤷ Valves Included
  • : Sold Separately
  • ⤷ Fuel Type
  • : Central Heating | Electric | Dual Fuel
  • ⤷ Wall to Centre of Inlet
  • : 65-80
  • ⤷ Heating Element Included
  • : Sold Separately
  • ⤷ Element Type
  • : Standard | Thermostatic
  • ⤷ Brackets Included
  • : Yes

Additional Info & Downloads

Download PDF Download the Heating Element Manual Instructions Pdf File Download PDF Download the Details Of Heating Elements Pdf File


Technical Images


Customise Your Product

Optional Accessories
Optional Accessories

Reina provides optional accessories that you may require for the installation. The manufacturer highly recommends these Accessories. Please Note: The image shown is for illustration purpose only.

Total: £98.35 5 Working Days Approx QS Supplies

Product Variations Info & MFC Code
Details For Steel Designer Radiator - Anthracite
Width 500mm 800mm 1200m
Finish Anthracite Anthracite Anthracite
Pipe Centres 470 470 470
Wall to Pipe centres 65-80 65-80 65-80
Wall Distance 80-95 80-95 80-95
Tube Quantity 5 7 10
Total Gap 4 6 9
Fuel Type Central/Electric/Duel Central/Electric/Duel Central/Electric/Duel
Watts - Delta-70 317 507 761
BTU - Delta-70 1082 1730 2596
BTU - Delta-60 887 1418 2128
BTU - Delta-50 698 1116 1675
BTU - Delta-45 608 972 1458
BTU - Delta-40 525 840 1260
BTU - Delta-35 440 703 1055
BTU - Delta-30 357 571 857
BTU - Delta-25 139 222 334
MFC RND-SRN5050A RND-SRN5080A RND-SRN5120A
Details For Steel Designer Radiator - Chrome
Width 500mm 800mm 1200m
Finish Chrome Chrome Chrome
Pipe Centres 470 470 470
Wall to Pipe centres 65-80 65-80 65-80
Wall Distance 80-95 80-95 80-95
Tube Quantity 5 7 10
Total Gap 4 6 9
Fuel Type Central/Electric/Duel Central/Electric/Duel Central/Electric/Duel
Watts - Delta-70 225 357 536
BTU - Delta-70 767 1218 1828
BTU - Delta-60 629 998 1498
BTU - Delta-50 495 786 1179
BTU - Delta-45 431 684 1027
BTU - Delta-40 372 591 887
BTU - Delta-35 312 495 743
BTU - Delta-30 253 402 603
BTU - Delta-25 99 157 235
MFC RND-SRN5050 RND-SRN5080 RND-SRN5120

4 Features Included In This Product Explained

Mild Steel

Mild Steel

Mild Steel is the most common radiator material. It is inexpensive, available in a variety of designs and finishes, lightweight and durable.

Central Heating

Central Heating

'Standard' radiators and towel warmers are connected to your central heating system, so hot water flows through them to heat them.
Read more...

Optional: Dual Fuel

Optional: Dual Fuel

These radiators or towel warmers can run on a conventional gas-powered central heating system or via your mains electrical supply. You can choose whether or not you want your radiator or towel warmer to come on independently of your central heating system, which is especially useful in summer. These radiators are compatible with heating and hot water, whether the system is open (direct) or closed (indirect).

Optional Sleeving Kit

Optional Sleeving Kit

A sleeving kit in a radiator heating system are components or materials used to sleeve or insulate the pipes or tubes that circulate hot water or steam from the central heating source to the radiators or heating units. The sleeving kit provides thermal insulation and prevents heat loss, adding to the heating systems efficiency.

You've Selected which adds to a total of

Reviews & Ratings

Rate this Item.:

Questions & Answers

Submit Your Questions 1 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Mohammad Asked :

For electric towel rails, an optional extra is 'Liquid filling for electric only'. What is this? Aren't electric towel rails ready to go? What is this 'extra' filling thing?

Answered By QS Team Answered by the QS Technical Team

An electric radiator requires filling the tubes with a liquid in addition to the heating element. The radiator ready to go with only electric wirings is called a "Dry-Electric Radiator".
